AT 500VA -800VA Offline UPS

AT 500VA -800VA Offline UPS thumbnail-1
AT 500VA -800VA Offline UPS photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KEMAPOWER
Model Number:
AT 500VA -800VA
Contact Supplier Request Quote Chat Now
Foshan Kemapower Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name KEMAPOWER
Model Number AT 500VA -800VA
Phase Single Phase
Protection Overvoltage
Weight 12kg/24kg
Output Voltage 220V/110V+/-10%
Type Line Interactive
Application Instrumentation

Offline UPS



Key Features

1.Wide input voltage window
2.Boost and Buck AVR
3.Protection for short circuit, overload and battery low voltage
4.LED indication and audible alarm function
5.Intelligent battery management
6.AUTO start function is option
7.Automatic battery charging in UPS off mode (Option)

 AT  SERIES  TECHNOLOGY SPECS



ItemModelAT 500AT 650AT 800
 Capacity Output power500VA/300W650VA/390W800VA/480W
 Input Voltage range165~275Vac±5V (140--280v is option ) or 88 - 139Vac
 Frequency range50 or 60 ± 2.5Hz
 Output Voltage220V or 110V ± 10%
 Frequency50 or60 ± 6Hz
 Transfer time<10Ms
 WaveformModified sine wave (battery mode)
 Battery TypeSealed lead acid, maintenance free
 DC voltage12VDC
 Battery number1*12V/7AH1*12V/7AH1*12V/9AH
 Protection point    of low Voltage9.5VDC-10VDC
 Standby timeFull load >3min,half load >8min
 RechargeAfter fully discharged, charge 8 hours to 90% capacity
 Protecting Output overloadFuse & current limited when overloaded
 Battery low voltageAutomatically lock out the machine so as to protect the Battery from over discharging
 Short circuitFuse & current limited
 RestartAuto restart when AC recovery.
 Alarm Battery back-upSounding every about 4 seconds
 Battery lowSounding every about 1 second
 OverloadShutdown at once
 Indicator LEDLED indicator for line on, battery back-up, UPS cut-off
 Package sizeL*W*H(mm) 2PCS590*315*240385*315*235400*315*335
 Package weightKg, 2PCS91113.4







 AT 500VA -800VA Offline UPS

AT 500VA -800VA Offline UPS
