GIGA LX Cartons Folding Gluing Machine With Counter

Name: GIGA LX Cartons Folding Gluing Machine With Counter
Brand: GIGA LX
SKU: 112009201
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Application:

Food

Packaging Type:

Cartons

Shanghai Liu Xiang General Equipments Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

PORT OF SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Food

Packaging Type Cartons

Packaging Material Metal

Automatic Grade Automatic

Driven Type Electric

Power 22KW

Place of Origin Shanghai, China

Brand Name GIGA LX

Model Number LX-FG

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1:folding gluing machine
2:Component USA famous brand VALCO
3:Stacker output controllable
4:High speed 300sheet/m

LX-FG Automatic Folding and Gluing Machine Inline With Carton Machine

folding gluing machine

Carton folder gluer is full computerized
Touch screen input order, automatic adjust specifications.
Lateral scorer to facilitate folding.
Vacuum suction belt transmission to prevent slipping, and avoid scissors movement.
Both sides equipped with guiding rollers.
Imported USA VALCO glue spraying system, automatic non-contact tracking, and accurate coating.
Carton strapping machine moving parts are composed of imported ball screw and linear guides track;
Stacker and output are controlled by servo motor, max.speed 300 sheet/min.
Work independently or equipped with printer & slotter machine.
Max.machine speed: 300sheet/min.
Max.feeding size: 2500*1600mm
Min.feeding size: 650*400mm
Main motor power: 22kw
Total power: 50.8kw
Dimension: 12000*4810*2530mm
Total weight: 20 ton
