GIGA LX Manul Corrugated Cartons Cutting and Creasing Machine Chain Feeder

Name: GIGA LX Manul Corrugated Cartons Cutting and Creasing Machine Chain Feeder
Brand: GIGA LX
SKU: 112009007
Availability: InStock

US$ 30,000 - 85,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Other, Carton machine

Packaging Type:

Other, In steel pallet

Shanghai Liu Xiang General Equipments Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

port of China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Other, Carton machine

Packaging Type Other, In steel pallet

Packaging Material Other, Steel

Automatic Grade Semi-Automatic

Driven Type Electric

Power 9

Place of Origin Shanghai, China

Brand Name GIGA LX

Model Number LX406

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Semi-automatic chain feeding
2.Step-less speed changing make stable running
3.cardboard cutting and creasing machine

LX-406 Semi-automatic Rotary Die Cutter

Cardboard cutting and creasing machine main functions:

Semi-automatic chain feeding rotary die cutter - compact in design, easy operate, fine die-cutting
Step-less speed changing (from 20 to 80 pcs/min) make a stable running
Light, electric, and gas combined control, to make carton at one cutting, safe and efficient
Transmission gears are made of high quality alloy steel with fine treatment. Spraying circulation is adopted to lubricate the gears, reduce noise and prolong the service life
Pneumatic lifting device working synchronous with the feeding system (During the feeding operation the mould roller pressed and when the feeding stops the mould roller released to ensure the correct die-cutting of every paperboard)
Mechanical drive anvil roller transverse moves within 40mm and installed with radial differential device to spread wear evenly and to improve the life of anvil roller
Speed difference compensation device adjusts roller speed automatically to guarantee perfect cut, unformed carton size .
Phase adjustment, with harmonic device and transducer control, dynamic and static 360 degree motorized adjustment, easy and quick, Box machine are made in good quality.
