Home > Packaging & Printing > Packing Machinery > Multi-Function Packing Machine > GIGA LX Automatic Offline Folder Gluer Machine for Carton Box

GIGA LX Automatic Offline Folder Gluer Machine for Carton Box

Name: GIGA LX Automatic Offline Folder Gluer Machine for Carton Box
Brand: GIGA LX
SKU: 112008625
Availability: InStock

GIGA LX Automatic Offline Folder Gluer Machine for Carton Box thumbnail-1

GIGA LX Automatic Offline Folder Gluer Machine for Carton Box photo-1

US$ 51,000 - 70,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Application:

Other, carton box machine

Packaging Type:

Other, In steel pallet

Contact Supplier Request Quote Chat Now

Shanghai Liu Xiang General Equipments Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Port of China Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application Other, carton box machine

Packaging Type Other, In steel pallet

Packaging Material Metal, Other, Metal, Plastic and steel pallet

Automatic Grade Automatic

Driven Type Electric

Voltage 380V

Power 17kw

Place of Origin Shanghai, China

Brand Name GIGA LX

Model Number LX-FGO

Weight 13T

Dimension(L*W*H) 18000*2700*1800mm

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.offline folder glue
2.Got CE
3.Servo lead edge feed
carton stripping machinery

GIGA LX Automatic offline folder gluer machine for carton box

offline folder gluer / paper gluer machine / gluer machine

Specifications

1:Carton offline folder gluer machine
2:Component USA famous brand VALCO
3:Stacker output controllable
4:High speed 300sheet/m

Carton folder gluer machine is full computerized

automatic adjust specifications.
Lateral scorer to facilitate folder.
Vacuum suction belt transmission to prevent slipping, and avoid scissors movement.
Both sides equipped with guider rollers.
suitable for E,B,A and double wall paperboard.
Carton strapping machine moving parts are composed of imported ball screw and linear guides track;
Stacker and output are controlled by servo motor, max.speed 300 sheet/min.
Work independently or offline with printer & slotter machine.
Max.machine speed: 200sheet/min.
Max.feeding size: 2200*1000mm
Min.feeding size: 350*200mm
Main motor power: 17kw
Total power: 17kw
Dimension: 18000*2700*1800mm
Total weight: 13 ton
Folder gluer machine and gluing machine are made in good quality.

We provide loan to below business situation
1. The value of order over RMB 1 million (including 1 million).
2. Only for boxing machine LX308N, LX-608CN LX707N or corrugated machine production line include LXC-180NN, LXC-220H1.8N models.
3. We accept O/A (Open account), it based on the credit level of buyer's bank credit report.
4. The details please consult with our sales department.
