GIGA LX-708 corrugated carton box stapling machine
USD $200,000 - $600,000
/ Set
1 Set(Min.Order)
- 4 Set / Sets per Month
- PORT OF CHINA
- T/T L/C D/P D/A
You May Like
- Case Packer Pouch Cartoning Line for Packaging Doypack Bags
- Introduction of plastic hollow plaid production line
- Cartoning Machine Monoblock Case Packer for Packaging Butter Bricks
- Auto Bottle Shrink Wrap Packaging Machine
- Semi-Automatic Heat Shrinking Machine
- Automatic Heat Shrink Edge Banding Shrink Packaging Machine
Product Details
Condition: | New | Application: | Other, Carton and box making | Packaging Type: | Other, In steel pallet |
Packaging Material: | Other, Carton machine | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 380V | Power: | 40-145 | Place of Origin: | Shanghai, China |
Brand Name: | GIGA LX | Model Number: | LX708 | Dimension(L*W*H): | 8000mm*7000mm*2200mm |
Weight: | 9MT-22MT | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1.Computerized store9992.Dual system compensate device
3.Servo lead edge feeder
4.Box making machine with good quality
machine cartonator LX-708 Computerized High Speed Flexo Printing and Slotting and Die Cutting Machine
corrugated carton box stapling machine corrugated carton box stapling machine
Computerized carton box making machine main function... paper egg carton making machine
- Keep the functions of intelligence zero returning, memory reset and automatic order formation....
- Dual system of touch screen man-machine interaction and manual electrical control.
- All famous brand touch screen, PLC Controls and Frequency converter.
- Apply the joining with non-keypiece so as to decrease the connection gap and keep long term register accuracy lx607
- Designed and manufactured upon the standard of top demands, reliable performance and solid safety. The complete set of machine is operated computerized upon the designing principle of man-machine integration. E Flute corrugated cardboard could be used and printing with the machine LX708.
- It can do the job of setting, correction, lx708 execution, change and memory, etc. on the touch screen with precise data display in the shortest time.
- Adopts high-grade material and accessories.
- Transmission gears are made of high-quality alloy steel 20CrMnTi.
- Get to 60 degree and more after the process of carburization quench and fine grinding.
- Carton making machine prices and corrugated box machinery are very good.
We provide loan to below business situation
1. The value of order over RMB 1 million (including 1 million).
2. Only for box making machine LX708N, LX-708CN LX708N or corrugated machine production line include LXC-180NN, LXC-220H1.8N models.
3. We accept O/A (Open account), it based on the credit level of buyer's bank credit report....
4. The details please consult with our sales department....
1. The value of order over RMB 1 million (including 1 million).
2. Only for box making machine LX708N, LX-708CN LX708N or corrugated machine production line include LXC-180NN, LXC-220H1.8N models.
3. We accept O/A (Open account), it based on the credit level of buyer's bank credit report....
4. The details please consult with our sales department....
Feeder unit
- Rear kicker vacuum assist feeding system can adjust the wind rate according to the crook degree of the sheet so as to ensure the smooth feeding in. The wind rate is adjusted by the frequency converter. or Adopted Servo Control Lead Edge Feeder for optionLX708.or with pressure-free system for feeder
- Side guides, kicker plate, back guide motorized control with paper squaring function.
- Aluminium alloy kicker plate, light and antifriction Upper feeding roll is wrapped antifriction rubber and keep the function to adjust air pressure
- Feeding slide rail adopts linear bearing
- Continuous or skip feeding capacity with electronic counter.
- Feeding counter can be preset and display the production quantity.
- Linkage on automatic feeding and anilox roll can decrease the sheet waste.
- Suction dust remover capacity can eliminate the mass impurity on the printing surface so as to improve the printing quality.
Printing Unit
- Printing phase adjustment by PLC, touch screen control and motorized digital 360 degree. Printing cylinder keeps the function of zero return and can reset in dynamic and static condition...
- Planetary gear phrasing mechanism.Dynamic and static balance correction ensure stable running
- Loading and unloading of the printing plate motorized turn positive and reverse by pedal switch,lx608Adopts hanging mechanism
- Pressurized automatic lifting device working in with the feeding systerm
- Motorized digital display adjusts the transversal position of the printing cylinder within the range of 20mm..
- Printing phase fixing mechanism with electromagnetic clutch....
Ink System
- Pressurized diaphragm pump
- Specially and finely reground crown is good for ink transmission.
- Steel anilox roll: chrome plated and engrave reticulate pattern with consistent net dots good for fine inking.
- Steel pipe coated by antifriction rubber.
- Stainless steel ink bucket with ease to clean and mainternance.
Slotter Unit
- Pre-scoring wheel: the sheet by pre-scored is no crush.
- Manual adjustment on the gap between scoring wheels within the range of 0-12mm//
- Upper scoring wheel coated by polyurethane avoid of crush on the sheet.
- Transverse movement of scoring wheel, doctor wheel and slotting head controlled polyfunctionally by PLC, touch screen and electromotive button.
- The slotting knives are made of alloy tool steel by heat treatment and teeth finely ground. The width is 7mm. Sharp teeth and endurable.
- Bi-plate trimming knives with sharp teeth and endurable.
- Slot phasing machanism is planetary gear structure...
- Slotting phase adjustment by PLC, touch screen conrol and motorized digital 360 degree in dynamic and static condition. Order can be preset.
Die Cutter Unit
- Mould roll and anvil roll can be apart by the air cylinder eccentric mechanism during non-woring condition
- Die cutting phase adjustment by PLC, touch screen control and motorized digital 360 degree in dyamic and static condition. lx708Order can be preset.
- Unique speed difference compensate device,
- Pressurized automatic lifting device working in with the feeding system
- Mould roll by transverse electromotive digital adjustment capacity within the range of 20mm.
- Planetary gear phrasing mechanism.
- Anvil roll and mould roll adopts high grade steel with finely reground and chrome plated.
- Balance correction enhances running stability.
- Mechanical drive anvil roll transverse moves within 30mm and installed with radial differential gear device The machine keeps the grinding device Installed with belt deliver stripping device, corrugated box making machine, corrugated carton machine could be made with good quality;
Stack Unit
- Sheet collection arm has manual and automatic operation methods.
- Sheet collection arms are in belt transmission adjusted tension independently. Numbers of sheet collection arms is optional.
- The lifting of stacking bed is driven by strength chain.Piling height 1600mm.
