GIGA LX Semi-automatic Flute Laminator Machine M1300

GIGA LX Semi-automatic Flute Laminator Machine M1300 photo-1
US$ 120,000 - 230,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Carton and box and cardboard
Packaging Type:
Other, In plywood case
Payment & Shipping
Payment Methods:
Port of Shipment:
PORT OF SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Other, Carton and box and cardboard
Packaging Type Other, In plywood case
Packaging Material Other, PALLET
Automatic Grade Semi-Automatic
Driven Type Electric
Voltage 380-440
Power 7KW
Place of Origin Shanghai, China
Brand Name GIGA LX
Model Number LXTMB-F
Dimension(L*W*H) 7400*1530/1830/2080/2250/*1400MM
Weight 3.2MT-5.5MT
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Turnup bridge plate cleaning
2.Discontinuous water-circulate
3.Semi-Automatic feed laminating machine
4.A/C/B/E cardboard

 GIGA LXTMB-F Series Semi-automatic Flute Laminating Machine (Single Labor)

 Semi-automatic Flute Paper lamination machine

  1. Lamination machine main features.
  2. Turnup bridge plate is convenient for cleaning, discontinuous water-circulating system ensures washing clean.
  3. Automatic feeding for bottom sheet, manual feeding for top sheet (feding from side for top sheet is optional).
  4. Flexible front register, bottom sheet is not exceeding the top sheet, and its adjustable for the front-and-rear lamination between bottom sheet and top sheet.
  5. Bottom sheet can be paperboard more than 300gsm, A/C/B/E corrugated cardboard.
  6. Movable lengthened pressing section is optional for corrugated board thicker than B flute, and its lenth is more than 800mm
  7. Optional: PLC integrated program module control.

We provide loan to below business situation
1. The value of order over RMB 1 million (including 1 million).
2. Only for fully automatic corrugated box making Machine  LX308N, LX-608CN LX707N or corrugated machine production line include LXC-180NN, LXC-220H1.8N models.
3. We accept O/A (Open account), it based on the credit level of buyer's bank credit report.
4. The details please consult with our sales department.



Paper laminating machine main Technical Parameter.



Model

LXTMB-1000F

LXTMB-1300F

LXTMB-1450F

LXTMB-1600F

Max. sheet size

1000X1100mm

1300X1100mm

1450X1100mm

1600X1100mm

Min. sheet size

320X450mm

320X450mm

320X450mm

320X450mm

Total electric consumption

7kw

7kw

7kw

7kw

Speed

0-90m/min

0-90m/min

0-90m/min

0-90m/min

eight

3.2t

4.2t

4.8t

5.5t

Overall Dimensions

7400X1530X1400mm

7400X1830X1400mm

7400X2080X1400mm

7400X2250X1400mm





GIGA LX Semi-automatic Flute Laminator Machine m1300GIGA LX Semi-automatic Flute Laminator Machine m1300

 GIGA LX Semi-automatic Flute Laminator Machine m1300GIGA LX Semi-automatic Flute Laminator Machine m1300GIGA LX Semi-automatic Flute Laminator Machine m1300GIGA LX Semi-automatic Flute Laminator Machine m1300

GIGA LX Semi-automatic Flute Laminator Machine m1300GIGA LX Semi-automatic Flute Laminator Machine m1300GIGA LX Semi-automatic Flute Laminator Machine m1300

GIGA LX Semi-automatic Flute Laminator Machine m1300

GIGA LX Semi-automatic Flute Laminator Machine m1300
