UL DLC AC100-277V 40W Ceiling Suspended Recessed LED Panel Light Office Salon 1*4FT

Our led chip the largest lumen can reach 130lm/w, the best CRI we can more than 90(CRI>90),normal we use CRI>80.

Our lamp bead the cooling effect is better,higher brightness,the light efficiency can reach above 97%

 LED Panel light save energy,take 36w 600*600 LED panel light for example,it lighting 8 hours every day.

1.The lumen of 1pc LED panel light amount to 3pcs general 14w T5 fluorescent.

   1 LED panel light about $20/PC,1 general tube light about $10/PC,so can save US$10 per used cycle.

2.LED panel light life time is 50000 Hours,T5 fluorescent is 3000 Hours,it means 1pc LED panel light amount to    16pcs general 14w T5 fluorescent,it will save US$150,beside,labor cost is free.

3.1pc LED panel light will expend 0.288 unit electricity,105.12 unit electricity every years,3pcs general 14w T5       fluorescent will expend 0.336 unit electricity,122.64 unit electricity every years,so LED panel light will save         17.52 unit electricity every year.

If the office install 10pcs LED panel light,10 offices,electric charge is $0.1/unit,LED panel lights will save $175.2,save light charge $1000.

1.Suspended to the ceiling:

   1) Mount the base on the back of the panel light

   2) Use the hanging wire,through the hole in the base

   3) Use the hanging wire,through the hole ing the other base

   4) Fixing the base and ceiling with screws

2.Surface Mounted

   1) Install three sheet metal tank

   2) Put the panel light in,make the panel light accordance with the metal tank

   3) Installation of fourth pieces of sheet metal tank

3.Embedded with clips(1)

   1) Remove the false ceiling

   2) Take out the ceiling flat panel light

   3) Through the connector link power

   4) Put the panel light in the ceiling,installation effects

4.Embedded with clips(2)

   1) Fix the clips on the panel light

   2) Put the light in the ceiling,use the clips to fix the light,and link power

   3) Installarion effects

UL DLC CE RoHS TUV- EMC & LVD/SAA/LM79/LM80/LCP

Our certification & Test Report (UL DLC CUL on process)

      ZJESL LED Panel Light on Official Test

           1. LED Panel Light Class Level: A+

(Reference-ErP6000hrs, report No. 15083382 002, Page 8 of 12)

2. Lumens Depreciation of LED Panel Light< 8% (International standard )

(Reference-ErP 6000hrs, report No. 15083382 002, Page 11 of 12)

3. Ambient Temperature: (15℃-40℃) -

(Reference-ErP6000hrs, report No. 15083382 002, Page 11 of 12)

& can be reached at 60℃(on process of testing)

 4. Driver information

 TUV EMC & LVD CE RoHS SAA LM79

 Ta=45℃, Tc=85℃

         5. Testing report by authoritative test organization

CE RoHS ErP LM79 - TUV

SAA C-tick LCP - CNAS (Testing L4595)

   6. LED Chip

Epistar Brand, SMD BY HONGLI

LM80/TM21 testing standard

We are an independent full-service exporter focused on providing the best service to export the lighting from China to the world. We have been in lighting business over 9 years.

More recently we have increased our LED Lighting manufacturing line to LED Spot lights, LED linear light , LED pendant lights, LED Tubes, LED Panels, as well as the LED Outdoor lights.

Our factory covers an area of 20000 square meters,Besides we had our professional optical lab, and our engineers had mater degree, and had full knowledge in lighting area,Our mission is to support the independent professional with good quality products in lighting area and advanced solution to give you an edge over your competitors in today's competitive world.
