Product Description of brick molding machine processing soncap certificate
Introduce of QMY10-15 brick molding machine processing with soncap certificate
1.QMY10-15 brick molding machine processing :Advanced techniques made the host machine
designed reasonably,and achieved box vibration,hydraulic stripping,omnidirectional automatically movement.
2.QMY10-15 brick molding machine processing works faster because of automatically feeding system.High quality of steel and precision welding
made the machine a longer service life and hydraulic system made less fault during work.
3.QMY10-15 brick molding machine processing : has the largest productivity than any other mobile block machines,
which with considerable strength with the fixed QT10-15 block machine.
This kind of brick machine is manufactured on the base of technical modifications to the original block shaping machines,
that is changing the former one-time-vibration into twice-vibrations of molding core.
So the block density becomes higher,shaping speed quicker and block strength more even.
This model of machine can be suitable to the customers who have any kinds of existing cement working sites.
Hydraulic pressure,No need pallets.
Specification of QMY10-15 brick molding machine processing with soncap certificate
QMY10-15 big brick making machine mobile brief introduction main technical parameters | |
Overall dimension | 3150*1800*2400mm |
Demold method | Hydraulic |
Turning method | Hydraulic |
Hydraulic system pressure | 16-20Mpa |
Excitation frequency | 3200Hz |
Total power | 16KW |
Total mass | 4200KG |
Molding cycle | 10-15S |
Molding | 10 Pcs/mould(400*200*200/390*190*190 mm) |
Capacity | 2000-9000Pcs/hour |
Types of bricks can be made | 390*240*190/390*190*190/390*115*190 All kinds of moulds can be made by customers' drawings |
Moving method | Automatically move and hydraulic steering |
Excitation way | Three-dimensional box excitation |
Raw material | Crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial material |
Item | Specification size | Quantity per mold | Cycle moulding | Per hour | Per day |
Hollow brick | 400*200*200 | 10pcs | 15-20s | 1800-2400pcs | 17280-21600pcs/day |
Porous brick | 240*115*90 | 64pcs | 15-20s | 11520-15360pcs | 92160-122880pcs/day |
Standard brick | 240*115*53 | 112pcs | 15-17s | 23700-26880pcs |
189750-215040pcs/day
|
|
