NFC Forum Tag TYPE 2,ISO/IEC 14443 ICSLI-1126 RFID HF Dry Inlay Rfid Inlay

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Model Number:

ICSLI-1126

Shenzhen RFID And Card Technology Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

HK SZ

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Model Number ICSLI-1126

Product code	ICSLI-1126
Product Category	Passive RFID antenna
Antenna Material	Aluminum Al (30μm) + PET (38μm) + Al bridge (10μm)
Chip	NXP Icode SLI
Frequency	13.56 MHz
RF Protocol	ISO-15693, 18000-3 Mode 1
Capacity	1024bits
Read Distance	2~4cm
Working life	100000 times / 10 years
Antenna size	11*26 mm
Wet inlay	15*30 mm
Thickness	0.07mm (chip location: 0.23mm)
Weight	0.01g
Working temperature	-20℃ to +60℃
Storage temperature	-25℃ to +65℃
Packing	1000pcs/roll or by customized
Read Distance	up to 2~4 cm depending on antenna geometry and reader configuration
Shelf life	one year Under the conditions of vacuum packaging,temp 20-30℃/humidity 20%-60%
Application	Identification,Card, Logistics, Library, Asset management, Payment, Access control

Handling

Inlays with ink marks are defective, do not use.
RFID Inlays or labels are sensitive product, do not bend or stretch
Static-free bag will be use for packing; always keep environmental static charge to a minimum.
InlaySolution reserves the right to modify, change, supplement or discontinue product offerings at any time without notice
All products from Unico Solution should be tested by the customer/user thoroughly to ensure the product meets the particular requirements. Unico Solution does not represent that this product is fit for any particular purpose or use.
