Help CenterHot Sale 14meters 20ft Dolly Linked 40ft Skeletal Ship Container Loading 3 Axles Inter Link Semi Trailer
Related Products
-
Dolly Fifth Wheel Linking Flatbed 3 Axles 40ft Container Interlink Trailer Truck With Twist LocksUS$ 12,500 - 18,000MOQ: 1 Unit -
Tandem Trailer Dolly 3 Axles 20ft Container Interlink Skeleton Super Link Trailer for SaleUS$ 12,500 - 18,000MOQ: 1 Unit
-
Dolly Design Double Axles Tandem 20ft With 40ft Container Flatbed Superlink Trailer for SaleUS$ 12,500 - 18,000MOQ: 1 Unit
-
Best Selling Gooseneck Container Trailer, 20 40ft Container Truck Chassis Semi TrailerUS$ 9,000 - 12,000MOQ: 1 Set
-
Cheap Port Trailer, Container Trailer, 20ft Skeleton Container Chassis Truck Semi TrailerUS$ 6,000 - 9,800MOQ: 1 Set
WELCOME TO JUYUAN
Product Information | |||||
Product | Flatbed or skeleton type trailer | | |||
Brand Name | Aotong Brand | ||||
Announcement (batch) | 229 | ||||
Place of Origin | Shandong province, China | ||||
Color | Any color will be available | ||||
Manufacturer | Liangshan Juyuan special vehicle manufacturing Co., Ltd | ||||
Specifications | |||||
Parameter | |||||
Outside Dimensions (L*W*H) | (6000-17000)*2500*1550mm | ||||
Rated Load | 45000 kg | ||||
Tare Weight | 7000 kg | ||||
Wheel Base | 8390+1310+1310 (mm) | ||||
Twist lock No | 12 | ||||
Running Gear | |||||
Tires | specification | 12R22.5-18 | |||
No. of tires | 8/12/16 | ||||
Spare tire carriers | 1 or 2 | ||||
Axles
| Brand | FUWA (BPW optional) | |||
No. of axles: | 2/3/4 | ||||
Axle-load | 13000kg | ||||
Wheel rim | 7.50-20 rim or 8.00 | ||||
Suspension | rigid suspension,10 pcs leaf-spring | ||||
Brakes | brand | TKL brand | |||
Brake chamber | double air chamber | ||||
System | Dual line braking system /ABS | ||||
Under Frame | |||||
Departure Angle | 16 | ||||
Front/Rear Overhang | 1890mm | ||||
Main Beam | material | I beam ,Q345B, automatic submerged arc welded | |||
specification | Height is 500mm,upper plate is 14mm,lower plate is 16mm,middle is 8mm | ||||
Cross Beam material | Q235B | ||||
Side beam | Channel steel | ||||
Plate form | Steel Sheet 3mm thickness or diamond plate(Also can choose other thickness ,such as 2mm,2.3mm,4mm,5mm,6mm) | ||||
King Pin | 50# or 90# | ||||
Landing gear | 28Ton | ||||
Accessory | One tooling box with a set of standard trailer tool | ||||
Electrical | |||||
Voltage | 24V | ||||
Receptacle | 7 ways (7 wire harness) | ||||
Lights | Front corner marker lamp :red ;reflector lamp :white | ||||
Side marker :orange | |||||
Rear lamp :red; rear reflector :white; turn single lamp :orange | |||||
Painting ,marking and side guard can according to the customer’s requirement | |||||
PACKAGING & SHIPPING
We transport the semi trailers by bulk or container. Our factory possesses long-term cooperation with ship agency which can provide you lowest shipping fee.
MORE DETAILS
Functions :
1. This series flatbed and skeleton continer semi trailers are mainly used in heavy duty transportation for construction or logistic companies, such as container transportin
2. The capacity is for 20ft,30ft,40ft,45ft,48ft,53ft containers, we can manufacture it according to your needs.
3. The axles can be Fuwa / Bpw with different tonnages by your need with price differences.
4. The suspensions can be: Air suspension, mechanic (leaf spring suspension), bogie suspension, etc
5. The loading deck can be concave beams, tire appeared cover, totally flatbed, or extendable.
6. The loading ramps can be rear end designed, or front loading ladders, which can be mechanic spring ladders and hydraulic loading ramps by different needs
Detail process:
1. Send us inquiries on your desired product / mdel through our contact information.
2. We shall reply you within 12 hours.
3. Negotiations on your needed configuration.
4. Configuration on the tech data.
5. Sign contract.
6.30% down payment or LC issuing.
7. Production
8. Manufacturig process updated news.
9. Production completement.
10. Shipment
11. Custom Clearance
12. A/S service for 1 year.
Export Market Distribution:
Market | Total Revenue (%) | Main Country |
The Middle East | 22.8 | UAE,Bahrain,Iran,Iraq,Israel,Jordan,Kuwait,Lebanon,Oman Qatar, Saudi Arabia,Syria,Yemen,Egypt |
Southeast Asia | 21.5 | Vietnam, Philippines,Laos, Kampuchea, Thailand, Burma, Malaysia, Singapore, Indonesia, Brunei, East Timor. |
Central Asia | 5.5 | Kazakhstan, Uzbekistan, Kyrgyzstan, Turkmenistan, Tajikistan |
Other Asia country | 5.4 | South Korea,India,Pakistan,Turkey |
South America | 8.8 | Brazil, Bolivia, Uruguay, Peru, Chile, Argentina, Dominica, Cuba, Venezuela,Nicaragua,Guatemala,Ecuador,Bolivia and so on. |
Europe | 7.8 | Russia,Belarus and so on. |
Africa | 27.4 | Congo, Tanzania, Ethiopia, Djibouti, Kenya, Angola, Chad, Egypt, Sudan, Libya, Tunisia, Algeria, Sudan, Egypt, Libya, Eritrea, Uganda, Rwanda,Burundi and the Seychelles. Mauritania, Western Sahara, Senegal, Gambia, Mali, Burkina Faso, Guinea, Guinea-Bissau, Cape Verde, Sierra Leone,Liberia, Côte d'Ivoire, Ghana, Togo, Benin, Niger, Nigeria and the Canary Islands. Cameroon, Equatorial Guinea, Gabon and Zambia, Angola,Zimbabwe, Malawi, Mozambique, Botswana, Namibia, and so on. |
North America | 0.8 | Canada ,America,Mexico |
1. Can i have samples of this type of trailer to test the quality?
Yes, you can buy any samples to test the quality,our MOQ is 1 set.
2. What's the delivery time and can you lower the price?
It depends on your order. The delivery time is within 15 workdays after we received your prepayment. If you have place an order of large quantities, then ,of course, the price can be lowered.
3. Can i customize the painting and the trailer design?
Yes, we offer customized design and logo for reasonable type.
4. What's the payment method?
TT 30% as Deposit, Balance Before shipment by TT or L/C at sight
5.How do you ensure its quality?
We are direct factory and we have professional quality inspector.We will not let any imperfections departure from our factory.
6.Can you provide the certificate we need?
Yes,We can provide the certificate you need,such as FORM E,Certificate of origin,CNCA,SONCAP,ASME,DOT,ECE as so on.
FACTORY & PRODUCTS
We are direct manufacturer and we have strong producing capacity and R&D capacity!Our raw material and OEM parts including axle, suspension, tyre, are purchased centralizedly by famous brand , every node will be inspected strickly. Moreover, advanced equipment rather than only worker is been applied during the whole producing process to ensure the welding qulity.
CONTACT PERSON
24 hours on line ,waiting for your kind inquiry
Please contact Coco Yu for details.
Phone/Whatsapp/Viber: +86 15650187200
skype:coco.yu1989
wechat:cocoyu8910
QQ:1973009824
Welcome to our factory,we will pick up you from airport.
