Fine performance
Insulating glass is made by separating two or more pieces of glasses with effective support and well-proportioned partition, and felting and pressurizing their edges with dry gas space between the glass layers. Insulating Glass usually has single-cavity and double-cavity structures.
1.Energy conservation heat preservation and heat insulation
The heat insulation of Insulating Glass is the more satisfying one among all the present deep processed glass products. Especially, the application of LOW-E Glass. inertgas filling and warm edge technology makes the heat insulation of Insulating Glass reach its optimization.
2.Comfortableness Sound insulation and noise reduction
nsulating Glass is the ideal material for sound insulation and noise reduction and can effectively reduce the sound level in a large range. Under the obstruction of Insulating Glass, all kinds of noises can be steadily reduced by more than 30db,Another 5db can be reduced further if inert gases have been filled in.
3.Environmental protection Low Temperature but No dew
The most fulsome trouble caused by window glass must be the dew on the surface of the glass in high latitude zones. The wet window frame is the perfect bed for bacteria breeding. This will not only bring visual uncomfortableness but also will even be the inducement for people’s sickness in winter. The sufficient quantity of desiccant filled in the spacer strips of Insulating Glass can effectively absorb the water vapor in the air cavity, including that infiltrated from the outside, The heat insulation of insulating glass successfully solve the problem of dew on the inner layer of glass and make the indoor glass surface get rid of dew so that the trouble puzzling people has been eliminated.
Glass types |
Insulating glass , tempered insulating , low-e insulated glass, hollow glass, double glazing glass, sealed insulating glass , window glass |
Specification |
1) Min size :300x300mm Max:3500x2000mm 2) Thickness:12mm-60mm 3) The thickness of Aluminium strip: 6A, 9A, 12A, 15A, 16A, 19A 4) Gas filling:Argon 5) Products can be combined by clear float glass, tinted glass , reflective glass, low-e glass , tempered glass , laminated glass ect. |
Features |
1) Thermal performance 2) Energy –saving :building materials 3) Sound insulation 4) No dewing in low temperatures 5) Create aesthetic senseto building |
Quality standard |
CCC , ISO9001, GB/T11944-2002 insulating glass standard china |
Applications |
hotel, restaurant, airport, hospital, lab; and instruments, electronic, broadcast, TV, where the constant temperature and moisture, sound and heat insulating are need, also including the luxury houses, food cubicle, refrigerator and so on.
|
Detailed products description
1) Min size :300x300mm, Max size :3500*2000mm
2) Total thickness range 12-60mm
3) Aluminium strip :6A, 9A, 12A, 15A, 16A
4) Low-e laminated glass or tempered glass also available
Our Services
Manufacture factory
Free samples
OEM services, logo printed is available
High quality: best quality with good quality float glass , advanced equipment and first glass technology
Safety sea worthy packing, reduce the breakage
Your information required:
1,Glass sizes & Thickness
2,Edge requirement & Holes or cut-outs requirement,better with drawings
3,Performance data & color (for low-e glassor tinted float and refective glass )
4,Quantity
Our terms:
1,price terms: FOB TIANJIN OR DALIAN Or CIF your port
2,Payment terms: 30% TT,70% Against BL copy
3,Lead time: 15-20 days(Ordinary Order)
4,Packing: Plywood or wooden crate,with paper or cork between each two glass sheets.
