Help Center35W Slim Ballast HID
Related Products
-
The New H1 Xenon Car LightUS$ 6 - 8MOQ: 5 Pairs -
New&high Brightness Hid Xenon KitUS$ 9 - 18MOQ: 1 Set
-
Xeno HID KIT H1 H3 H6m H4 H7 H8/H11 9004 9005 9006 9007 D2S D2R 6000K H9 H10 H13 Xenon Light BulbUS$ 1 - 25MOQ: 10 Sets
-
MINI H4 All in HID Set 35W Xenon LightUS$ 15 - 30MOQ: 5 Sets
-
6000K HID Set 35W HID Xenon BulbUS$ 5 - 11MOQ: 5 Pairs
Specifications
Ballast HID1>35w slim digital
2>longspan NO noise
3>9-36v
4>2 year warrnty
Ballast HID
A.HID Ballast details:
1) Input Voltage Range DC9V~32V
2) Starting Voltage DC12.8V
3) Input Current 4.2A
4) Max. In-rush Current 15A
5) Output Power 52W-58W
6) Output voltage AC85V±15V
7) Output Frequency 260Hz~280Hz
8) Efficiency: ≥84%
9) Ignition pulse - Typical peak Voltage 23kV Typ. 1s
10)Cooling method - Natural cooling
11)Input Protection, Under voltage protection at 6V±1V
12)Over voltage protection at 34.5V±1V
13)Input connection-reverse protection
14)Output Protection, Short circuit protection between two outputs
15)Open circuit protection between two outputs
16)The ballast matches lamps as H1, H3, H4, H4 (H/L), H7, H8, H9, H10, H11, H13, 9004, 9005, 9006, 9007, 880, 881
B:Ballast Function:
A. Overvoltage Protection
B. Short Circuit Protection
C. Undervoltage Protection
D. Overcurrent Protection
E. Circuit Protection
F. Waterproof, Anti-dust, Shockproof
