Specifications
Tubular MotorOur nanyang tubular motors in complete models from 3N.m to 300N.m in diameter of 35mm, 45mm, 59mm, 92mm.
Tubular Motor
Non -malfunction for the brake
Double sided magnetism, cone magnetism, electromagnetism brake system is used in this new type motor in order to meet different customers'requirement. It takes our team many years' research and test for the material of brake system which makes it perfect.
Adopted the plastic sealed technology, all the components have the accurate location dimension, low coefficient of the variation, and the service life time can be amounted to 10 years. Advanced design and crafts, the highest torque
Low noise delicate design and manufacture, the lowest noise is less than 38db, nearly silent move is bigger than the similar products in the same nt .
Strong intensity Adopted the special material, the gear is more wear-resisting, toughness and steel feature is more stronger which will increase the service life of the gear box.
Oil proof The sealed structure helped the gear oil hard to leak, ensure the gear works normally longer.
Accurate limit The accuracy for limit is <+-0.5 degree tolerance, limit configuration by screw pole drive makes accuracy for limit <+- 1.5 degree
Large effective limit Reasonable and compact design increases effective distance for limit very much, and the effectiveness could reach 50 circles.
Build-in remote control Good quality and stable receiver built in motor not only shorten the installation time ,Effective distance for remote control system is more than 30m
| Model | Dia. | Torque | Speed | N.W. | Current | Power | Max turns | ||
| mm | Nm | rpm | Kg | A | W | turns | |||
| JL1-3 | 35 | 3 | 17 | 28 | 1.6 | 0.60 | 120 | 20 | 39 |
| JL1-6 | 35 | 6 | 14 | 28 | 1.6 | 0.70 | 120 | 20 | 39 |
| JL1-6 | 35 | 6 | 14 | 17 | 1.6 | 0.70 | 160 | 20 | 39 |
| JL1-10 | 35 | 10 | 14 | 17 | 1.6 | 0.75 | 160 | 20 | 39 |
| JL1-13 | 35 | 10 | 14 | 1.6 | 0.75 | 160 | 20 | 39 | |
110Vac/60Hz
| Model | Dia. | Torque | Speed | N.W. | Current | Power | Max turns | ||
| mm | Nm | rpm | Kg | A | W | turns | |||
| JL1-3 | 35 | 3 | 16 | 36 | 1.6 | 1.04 | 120 | 20 | 39 |
| JL1-6 | 35 | 6 | 16 | 36 | 1.6 | 1.04 | 120 | 20 | 39 |
| JL1-6 | 35 | 6 | 16 | 20 | 1.6 | 1.32 | 160 | 20 | 39 |
| JL1-10 | 35 | 10 | 16 | 20 | 1.6 | 1.32 | 160 | 20 | 39 |
Insulation Class: Class F (Class H is available)
Noises: Less than 45dB
Thermal temp.: 140°C
Protection Index: IP44
Working time: S2- 4min
Cable length: 1.8m (custom-tailor available)
Cable type: 0.75mm2*4
Easy adjustable mechanical limit switch with receiver
