aluminium coil coated

Specifications

1.aluminium coil for aluminium composite panel
2.Polyester Coated Aluminum Coil
3.Special Surface Treatment



Usage of product

1)For Aluminum Composite Panel

2)For Ceiling/Roof system (PE/PVDF)

3)For Heat-Preservation Panel/ Gutter/Fence,etc.

Paint Suppliers

PPG, Becker, Valspor & Akzo-Nobel



PE coated aluminium coil

Specification

Thickness     0.10mm-0.60mm

Width           300mm-1590mm

Alloy           1100; 3003; 3004; 3005;8011;

paint:          polyester

Weight        less than 3.5mt/coil

ID                            76mm/150mm/405mm/505mm

OD                           less than 1400mm





Technical Specification

TESTING ITEM	TESTING RESULT
THICKNESS OF COATING MICRON	17+/-1
PENCIL HARDNESS	>=HB
T BEND  (T)	≤1
ADHESION	CROSS CUT ADHESION≥1 GRADE
IMPACT RESISTANCE	5KG/M  NO CRACK
BOILING WATER RESISTANCE	2 HOURS NO CHANGE
COLOR DIFFERENCE	E≤1
SOLVENT RESISTENCE	PASSED 100 TIMES RUBBING





















Business terms

FOB Price     USD 3,000-4,000/ metric ton

Min. Order     10 metric ton

Port of Delivery  Shanghai

Packaging      Packed in wooden pallet

Delivery Time Within 30 days after the deposit

Supply Ability   2,000metric tons per month



Packaging Packed in wooden pallet(eye to sky & eye to wall) L*W*H less than 1600mm*1400mm*1600mm Weight/Coil 2.5-3.0mt/coil Coil/Container 8-10coils/container











Shanghai Jixiang Industry is a manufacturer, which has dedicated to building materials for 13 years. Our sales outlets extended to all large and middle-sized cities of China, products exported to 50 countries and regions such as Russia, Southeast and Europe.









Inspection Device



Welcome all friends from all walks of life to Shanghai Jixiang Industry Co.,Ltd .
