underground mini loader with 1500kg capacity DLZ926E
1.YTO diesel engine is adopted, with strong power.
2.Applying hydrodynamic transmission technology, single stage, 3 elements torque converter owns simple structure and high reliability.
3.Controlled by flexible shaft, hydraulic power shift gearbox with 2 forward and 2 reverse gears makes operation easy.
4.Single pump, split flow working hydraulic system makes lower consumption and excellent performance.
5.Double sealed hydraulic pipeline joints with 24°awl and O ring of international standard, avoiding oil leakage;
6.Load sensing fully hydraulic steering system makes operation easy.
Bucket capacity |
1 m3 |
Min. turning radius |
4600mm |
Rated load |
1500 kg |
Steering angle |
30º |
Dumping height |
1800 mm |
Min. ground clearance |
320mm |
Dumping reach |
920 mm |
Wheel base |
2550mm |
Boom lifting time |
3.6 S |
Tread |
1650mm |
Total cycling time |
9 S |
Engine model |
Xin Chai 4105 |
Max. speed |
17km/h |
Rated power |
60kW/2400rpm |
|
Max. breakout force |
55 kN |
Tyre |
15/70-18 |
Max.drawing force |
51kN |
Overall dimensions |
5580*2020*1760 |
Max. Gradeability |
28° |
Operating weight |
5300kg |
