Wolwa GN30 Mini 4x4 Wheel Hydraulic Dumper With Self Loading System

Wolwa GN30 Mini 4x4 Wheel Hydraulic Dumper With Self Loading System photo-1
Wolwa GN30 Mini 4x4 Wheel Hydraulic Dumper With Self Loading System photo-2
Wolwa GN30 Mini 4x4 Wheel Hydraulic Dumper With Self Loading System photo-3
US$ 7,000 - 7,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
Wolwa
Model Number:
GN30
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Brand Name Wolwa
Model Number GN30
Place of Origin Shandong, China
Type Mini Loader
Moving Type Wheel Loader
Rated Load 3000Kg
Certification ISO9001
Warranty 12 Month
After-sales Service Provided Engineers available to service machinery overseas
3ton Wheel dumper GN30

Product Introduction

1 Mini dumper 3 ton/GN 30 4*4 Drive Hydraulic steering, can unload materianls smoothly by strong hydraulic pressure unloading system

2 Low walking speed, short-distance transport of bulk materials

3 Easy opration, small turning radius can be used in a narrow environment.

4 With self loading bucket can realize the mutifunction tools. Wtih full seal cabin optional.

5 Deutz Engine as Optional engine which makes the performance reliable.

6 Off road wider tyres as option, can work in muddy and bumpy road.

7 With bucket 180 rotate can raalize side dumping and dumping in each direction can have high working.

Specification

Model

GN30

Engine

Model

Quanchai 490

Type

In-line, water-cooled, 4 cylinders, 4 stroke ,diesel engine

Rated power

37KW/2300RPM

Hydraulic system

Type

Hydraulic steering and hydraulic tipping

Hydraulic pump power

16mpa

Hydraulic pump

Gear pump

Transmission

Gear box

Geared

Clutch

Dry,fricted

Shift

3forward,1reverse

Max speed

24km/h

Drive Axle

front axle fixed, rear axle oscillation (+ / - 11)

Performance

Bucket capacity

1.6m3

Max tractive force

45KN

Max grade capacity

30°

Rated loading weight

3000kgs

Total operating weight

2650kgs

Overall dimension

Total length

4150mm

Total width

1950mm

Total height(including cabin height)

2700mm

Wheel base

2150mm

Tread

2660mm

Mini Turning radius

5000mm

Brake system

Service brake

Oil

Parking brake

Increase within the hoof remote control with soft shaft type

Oil tank

Diesel oil tank capacity

50L

Hydraulic oil tank capacity

30L

Water tank capacity

10.5L

Tire

Tire model

12-16.5

Drive way

4*4

Shipment

1unit in 20 GP,3Units in 40ft container

Option

Cabin

DEUTZ engine



Figure Photos

Wolwa GN30 Mini 4x4 wheel hydraulic dumper with self loading systemWolwa GN30 Mini 4x4 wheel hydraulic dumper with self loading systemWolwa GN30 Mini 4x4 wheel hydraulic dumper with self loading systemWolwa GN30 Mini 4x4 wheel hydraulic dumper with self loading system
