NFC Type 2 Ntag216/215 Tags With Number Printed

US$ 0.15 - 1.5 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

XCC

Model Number:

KT16040705

Shenzhen XCC RFID Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name XCC

Model Number KT16040705

Manufactuer:XCC RFID

1) RFID maufactuer experiences since 1996
2) 10 000 square meters factory
3) Export since 2007

Place of origion: Dongguan, Guagdong

NFC Type 2 Ntag216/215 Tags With Number Printed

Features of Ntag216 NFC tags

1. Customized materil, size, colour base on your specific requires

2. Ntag213/215/216 NFC wet inlay are the newest with stable reading performance, widely used in AD, marketing, and society activity

3. Paper on front and adhesive layer on back, esaily used

4. High-class etched aluminium antenna

Specification of NFC tags

1.Size	85.5mm54mm, 50mm50mm, Φ50mm, Φ30mm or customized
2.Material	PVC , PET , ABS, Silicone, Paper
3.Chips available	Mf Ultralight/Ultralight-C/NTAG 203/210/215/216
	Desfire series 2-8K, Mifar plus series
4.Memory Size	64Byte/192Byte/168byte
	1K-8K
5.Working Life	5~10 years
6.Working Temp	-40~65°C
7.Available Craft	4-color offset printing, Silk-screen printing ,Thermal printing ,Digit printing , Magnetic stripe , Barcode, Hot-stamping gold/silver color , Signature panel , Series number marking, Hole punch,UV printing etc.
8.Application:	Commercial media & ads
	Business card & calendar
	Social media
	Product authentication
	E-payment

Four type Of NFC Tags

Type 1: Type 1 Tag is based on ISO/IEC 14443A. This tag type is read and re-write capable. The memory of the tags can be write protected. Memory size can be between 96 bytes and 2 Kbytes. Communication Speed with the tag is 106 kbit/sec. Example: Innovision Topaz
Type 2: Type 2 Tag is based on ISO/IEC 14443A. This tag type is read and re-write capable. The memory of the tags can be write protected. Memory size can be between 48 bytes and 2 Kbytes. Communication Speed with the tag is 106 kbit/sec. Example: Ultralight, ntag213/215/216
Type 3: Type 3 Tag is based on the Japanese Industrial Standard (JIS) X 6319-4. This tag type is pre-configured at manufacture to be either read and re-writable, or read-only. Memory size can be up to 1 Mbyte. Communication Speed with the tag is 212 kbit/sec. Example: Sony Fe-lica
Type 4: Type 4 is fully compatible with the ISO/IEC 14443 (A & B) standard series. This tag type is pre-configured at manufacture to be either read and re-writable, or read-only. Memory size can be up to 32 KBytes; For the communication with tags APDUs according to ISO 7816-4 can be used. Communication speed with the tag is 106 kbit/sec. Example: Desfire series chips
