13.56MHz ISO14443A Proximity S501K RFID Key Tag For Door Access Control
Description:
1)Model number: XCC01
2)Material: ABS housing
3)Color options: Red/ Blue / Yellow / purple /Black/Green/Grey
4)Operating Temperature: -20C ~ +55C
5)Storage Temperature: -25C ~ +60C
6)Chip Available:a.125Khz Only Read TK4100 EM4200
b.125Khz Read/Write T5577/EM
c.13.56Mhz Read/Write:1KS50 FM11
d.NFC Ultralight/Ntag203/Ntag213
7)With Keyring
8)Custom Size
9)Logo Printing(one color Two Color)
Personalization:
1)Silk-screen printing with logo
2)Ink-jet printing or Thermal transfer printing or Laser process of Serial Number
3)Chip encoding
4)Rings or thread is optional
Application:
Access control / Time attendance / Loyalty System / Payment NFC system
Manufacturer :XCC RFID
1)17 year smart card manufacturer experience
2)more than 10000 square meters factory
3)Export since 2007
4)Advanced production equipment and complete quality guarantee system
5)Insist on the concept of Integrity Managment since 1996s
Place of original:Donggaun city, Guangdong province,China
Factory direct supply
Customized size and shape
Fabulous printing and craft
Can be packed with opp bag as protection
Product Image:
|
Ultralight (UL) |
Ultralight C(ULC) |
Ntag203 |
1K |
Available Memory |
48byte |
148byte |
144byte |
752byte |
URL Length |
41characters |
132 characters |
132characters |
256characters |
Text length |
39characters |
characters |
132characters |
256characters |
NFC Type |
Type2 |
Type2 |
Type2 |
Type2 |
Date Example |
Short url,phone number,plece of text |
Long url,smart poster,short contact(i.e name and phone number) |
Long url,smart poster,short contact(i.e name and phone number |
Full contact information |
Performance |
Good;fast chip and low data amount result in a quick read time |
Not great;the built in encryption slows down the read time |
Awesome;latest chip and antenna design and low data size result in quick read time |
Slow,due to older chip design and larger data size |
Formatting |
Blank can be NDEF formatted |
Blank Can be NDEF formatted |
NDEF formatted |
Blank can be NDEF formatted |
Cost |
cheap |
cheap |
cheap |
expensive |
Lockable |
yes |
yes |
yes |
Technically no,but tag locking can be |
Our Opinion |
OK,if you only need minimal storage .If you are going to use NDEF ,then it would be better to use the NTAG |
Similar to the NTAG,but performance is not that great.The additional data storage over the Ultralight is nice you aren’t to use |
The best all around chip to use if you’re using NDEF |
Only use this chip if you need the additional data storage |
