Dual power supply D-60A 5V 12V led SMPS quality guaranteed
- 1000 Piece / Pieces per Month
- ningbo shanghai shenzhen guangzhou
- Credit Card PayPal
You May Like
-
dual switching power supply D-60B 5V 24V
-
dual power D-120A led switch power supply quality guaranteed
-
switch power supply D-120B 5V, 24V DUAL output quality guaranteed
-
universal QUAD led 12v power supply Q-60B quality guaranteed
-
universal power supply D-120A LED SMPS DUAL output good quality
-
switching power adapter D-120B 120W LED SMPS good quality
Product Details
Place of Origin | Zhejiang, China | Brand Name | Aotoro | |
Model Number | D-60A | Output Power | 51 - 100W | |
Output Type | Dual | Input Voltage | Other, 85-132VAC/170-264VAC | |
Output Voltage | 5V,12V | Output Frequency | 10500HZ | |
Output Current | 4A,3A |
Product Description
Established in 1997, Yueqing Aotoro Electric Automation Co.,Ltd is a professional in the electronic sensors research and development, one of the most professional sensor manufactures China.Now, we have won high and good reputation from customers both at home and abroad with excellent products and competitive price. We special manufacture in photoelectric switch,proximity switch,solid state relay,switch power supply,magnetic relay,timer relay,counter, touch sensor, all of our product have already approved CE certificate. We always believe in that the enterprise could keep leading position in the market as long as we are seeking our object.With this spirit,we always try best to satisfactory our customers to enlarge markets.
MODEL
SPECIFICATION | D-60A | D-60B | ||
CH1 | CH2 | CH1 | CH2 | |
OUTPUT DC VOLTAGE | 5V | 12V | 5V | 24V |
RATED CURRENT | 4A | 3A | 3A | 1.8A |
OUTPUT CURRENT | 0.3-6A | 0.2-4A | 0.3-6A | 0.2-2.2A |
RIPPLE & NOISE | 75mVp-p | 150mVp-p | 75mVp-p | 150mVp-p |
LINE REGULATION | ±0.5% | ±1% | ±0.5% | ±0.5% |
LOAD REGULATION | ±0.5% | ±4% | ±0.5% | ±4% |
RATED POWER | 56W | 58W | ||
EFFICIENCY | 73% | 76% | ||
VOLTAGE ADJ. RANGE | CH1+10,-5% | CH1+10,-5% | ||
INPUT VOLTAGE RANGE | 85-132VAC/170-264VAC; selected by switch,240-370VDC | |||
INPUT AC CURRENT | 2A/115V 1A/230V | |||
INRUSH CURRENT | COLD STAR 30A/115V 60A/230V | |||
LEAKAGE CURRENT | <2mA/240VAC | |||
OVER LOAD PROTECTION | 105 ~ 150% rated output power, fold back current limiting, auto-recovery
| |||
OVER VOLTAGE PROTECTION | CH1:5.756.73V,cut off output power, auto-recovery | |||
FAN CONTROL, O.T.P. |
| |||
TEMP. COEFFICIENT | ±0.03%(050) ON+5V OUTPUT | |||
SETUP, RISE, HOLD TIME | 800ms,50ms,10ms/115VAC 300ms,50ms,80ms/230VAC | |||
VIBRATION | 10500Hz,2G 10min./1 cycle , period for 60min, each along X, Y, Z axes | |||
WITHSTAND VOLTAGE | I/P-O/P:1.5KVAC, I/P-FG:1.5KVAC, O/P-FG:0.5KVAC | |||
ISOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC | |||
WORKING TEMP. HUMIDITY | -10+60,20%90%RH | |||
STORAGE TEMP., HUMIDITY | -20+85,10%95%RH | |||
DIMENSION | 159*97*38mm | |||
WEIGHT | 0.55Kgs | |||
SAFETY STANDARDS | UL1012 | |||
EMC | FCC PART15 J CONDUCTION CLASS B |
Aotoro Technology support:
Index: passed the CCC, CE certification, all the technical indexes reach achieve national standard (GB/T14048.10-1999),
Technology: adopting new special IC, adopt the most complete technical design, with various protection circuit, anti-jamming measures, more stable performance.
by SMD production technology, product reliability and consistency.
Management: passed ISO9001 certification, all processes of production links is strict accordance with the standardization documents, never let any nonconforming into the market.
Appearance: by international standard method to design, structure more reasonable and more beautiful appearance.
Service: pre-sale, sale and after-sale tracking service is comprehensive, The first-class technical team, providing technical support, complete and spotless quality guarantee.
