ac Adapter 24v 2.1a Output S-50-24 Quality Guaranteed Switching Power Single Output

Name: ac Adapter 24v 2.1a Output S-50-24 Quality Guaranteed Switching Power Single Output
Brand: Aotoro
SKU: 111807501
Availability: InStock

Yueqing Aotoro Electric Automation Co., Ltd.

ac Adapter 24v 2.1a Output S-50-24 Quality Guaranteed Switching Power Single Output thumbnail-1

ac Adapter 24v 2.1a Output S-50-24 Quality Guaranteed Switching Power Single Output photo-1

US$ 6.5 - 11.8 MOQ: 5 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Aotoro

Model Number:

S-50-24

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

ningbo shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Aotoro

Model Number S-50-24

Output Power 1 - 50W

Output Type Single

Input Voltage Other, 85-132VAC,170-264VAC

Output Voltage 5V12V15V24V

Output Current 10A,4.2A,3.4A,2.1A

Specifications

switching power single output
1.S-50-5
2.AC input range selected by switch
3.looking by free

Established in 1997, Yueqing Aotoro Electric Automation Co.,Ltd is a professional in the electronic sensors research and development, one of the most professional sensor manufactures China.Now, we have won high and good reputation from customers both at home and abroad with excellent products and competitive price. We special manufacture in photoelectric switch,proximity switch,solid state relay,switch power supply,magnetic relay,timer relay,counter, touch sensor, all of our product have already approved CE certificate. We always believe in that the enterprise could keep leading position in the market as long as we are seeking our object.With this spirit,we always try best to satisfactory our customers to enlarge markets.

MODEL SPECIFICATION	S-50-5	S-50-12	S-50-15	S-50-24
OUTPUT DC VOLTAGE	5V	12V	15V	24V
RATED CURRENT	10A	4.2A	3.4A	2.1A
OUTPUT CURRENT	0-10A	0-4.2A	0-3.4A	0-2.1A
RIPPLE & NOISE	75mVp-p	100mVp-p	100mVp-p	100mVp-p
LINE REGULATION	±0.5%	±0.5%	±0.5%	±0.5%
LOAD REGULATION	±1%	±0.5%	±0.5%	±0.5%
RATED POWER	50W	50.4W	50.4W	50.4W
EFFICIENCY	71%	78%	78%	82%
VOLTAGE ADJ. RANGE	±10,-5%	±10%	±10%	±10%
INPUT VOLTAGE RANGE	85-132VAC/170-264VAC selected by switch
INPUT AC CURRENT	1.3A/115V 0.65A/230V
INRUSH CURRENT	COLD START 18A/115V 36A/230V
LEAKAGE CURRENT	<1mA/240VAC
OVER LOAD PROTECTION	105 ~ 150% rated output power, fold back current limiting, auto-recovery
TEMP. COEFFICIENT	±0.03%(050)
SETUP, RISE, HOLD TIME	200ms,100ms,30ms
VIBRATION	10500Hz,2G 10min./1 cycle , period for 60min, each along X, Y, Z axes
WITHSTAND VOLTAGE	I/P-O/P:1.5KVAC, I/P-FG:1.5KVAC, O/P-FG:0.5KVAC
ISOLATION RESISTANCE	I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC
WORKING TEMP. HUMIDITY	-10+60,20%90%RH
STORAGE TEMP., HUMIDITY	-20+85,10%95RH
DIMENSION	1599738mm
WEIGHT	0.5Kgs
SAFETY STANDARDS	UL1012
EMC	FCC PART15J CONDUCTION CLASS B

AOTORO Technology Support

Index: passed the CCC, CE certification, all the technical indexes reach achieve national standard (GB/T14048.10-1999), Technology: adopting new special IC, adopt the most complete technica l design, with various protection circuit, anti-jamming measures, more stable performance. by SMD production technology, product reliability and consistency. Management: passed ISO9001 certification, all processes of production links is strict accordance with the standardization documents, never let any nonconforming into the market. Appearance: by international standard method to design, structure more reasonable and more beautiful appearance. Service: pre-sale, sale and after-sale tracking service is comprehensive, The first-class technical team, providing technical support, complete and spotless quality guaranteed.
