Platform Small Scissor Lift

Specifications

Feature:

.optional ground type or underground type

.four oil synchronous circuit ,keep the height difference of two platform within 3mm

.optional electric release or pneumatic release

,extensible lifting platform,suppy more repair service

.mold machine through the whole process so that the parts are universal and interchangeable

.pass120% capacity dynamic load test and 150% capacity static load test

.ltalian oil seal to make sure no oil leakage

.solenoid valve has the emerd=gency

.optional 24v control box ,solenoid valve and eletromagent

Technical data:

Model no:EPO3032

Lifting capacity:3200kgs/7000lbs

lifting height:2120mm

overall width:1980mm

overall height:195-2120mm

runway width:540mm

rise/drop time;90/75s

power:2.2kw

moter:220v/380v
