Help CenterSensor Parking M30 E3F-DS70C1 Long Range Photoelectric Sensor NPN NO
Related Products
-
Parking Sensor System M30 E3F-DS70B1 Photoelectric Sensor Supplier Quality GuaranteedUS$ 5.4 - 9.7MOQ: 10 Pieces -
Photoelectric Sensor CDD-11N Diffuse NPN Round Sensor Guaranteed GuaranteedUS$ 11.16 - 11.16MOQ: 10 Pieces
-
Light Sensor CDD-40N Diffuse Distance 40cm Photoelectric Sensor Quality GuaranteedUS$ 11.16 - 11.16MOQ: 10 Pieces
-
Photoelectric Sensor E3JK-DS30D1 Photocell Switch Quality GuaranteedUS$ 6.8 - 14.1MOQ: 5 Pieces
-
E3JK-DS30M1 30cm Adjust Photoelectric Sensor Quality Guaranteed Detector SensorUS$ 6.8 - 14.1MOQ: 5 Pieces
Specifications
Sensor parking1.detecting distance:70cm
2.power supply:10-30VDC
tection:IP64
4.CE approved.packaging standard
Established in 1997, Yueqing Aotoro Electric Automation Co.,Ltd is a professional in the electronic sensors research and development, one of the most professional sensor manufactures China.Now, we have won high and good reputation from customers both at home and abroad with excellent products and competitive price. We special manufacture in photoelectric switch,proximity switch,solid state relay,switch power supply,magnetic relay,timer relay,counter, touch sensor, all of our product have already approved CE certificate. We always believe in that the enterprise could keep leading position in the market as long as we are seeking our object.With this spirit,we always try best to satisfactory our customers to enlarge markets.
|
Specification |
E3F series |
|||
|
Type (diffusing) |
Type(polarized retroreflective) |
Type through- beam) |
|
|
DC 3-wire NPN output |
NO | E3F-DS70C1 | E3F-R4C1 | E3F-10C1 |
NC |
E3F-DS70C2 | E3F-R4C2 |
E3F-10C2 |
|
| DC 3-wire PNP output | NO |
E3F-DS70B1 |
E3F-R4B1 |
E3F-10B1 |
NC |
E3F-DS70B2 |
E3F-R4B2 |
E3F-10B2 |
|
|
AC 2-wire SCR output |
NO |
E3F-DS70Z1 |
E3F-R4Z1 |
E3F-10Z1 |
NC |
E3F-DS70Z2 |
E3F-R4Z2 |
E3F-10Z2 |
|
|
5-wire relay output use DC power supply |
NO |
|
|
|
NC |
|
|
||
|
5-wire relay output use AC power supply |
NO |
|
|
|
NC |
|
|
||
|
5-wire relay output use free AC/DC power supply |
NO |
|
|
|
NC |
|
|
|
|
| Sensing distance | 0-70cm |
≤4m |
≤10m |
|
| Hysteresis |
20%max. of sensing distance |
|
|
|
Sensing object |
Opacity or Transparency |
Opacity Min. 36mm |
Opacity Min. 11mm |
|
Standard object |
100X100mm white lackluster paper |
TD-08 reflector |
|
|
Supply voltage |
DC type10-30VDC,AC type90-250VAC |
|||
Current consumption |
DC type5mA max,AC type:3mA max. |
|||
Response frequency |
DC type:100Hz max,AC type:20Hz max. |
|||
Control output |
Resistive load:200mA max., Inductive load:100mA max. |
|||
Circuit protection |
Reverse polarity,surge absorber |
|||
Operating temperature |
-10 to +60non-freezing condition |
|||
Residual voltage |
DC 3-wire type:1.5V max., AC 2-wire type:8V max |
|||
Insulation resistance |
Min. 20M500VDC |
|||
Enduring voltage |
AC1500V 50/60Hz for 1minute |
|||
Protection |
IP64IEC specification |
|||
Aotoro Technology support:
Index: passed the CCC, CE certification, all the technical indexes reach achieve national standard (GB/T14048.10-1999),
Technology: adopting new special IC, adopt the most complete technical design, with various protection circuit, anti-jamming measures, more stable performance.
by SMD production technology, product reliability and consistency.
Management: passed ISO9001 certification, all processes of production links is strict accordance with the standardization documents, never let any nonconforming into the market.
Appearance: by international standard method to design, structure more reasonable and more beautiful appearance.
Service: pre-sale, sale and after-sale tracking service is comprehensive, The first-class technical team, providing technical support, complete and spotless quality guarantee.
Payment
1. Full payment must be made within 15 days of placing your order.
2. The buyer is responsible for any tax and/or duty charged by their country.
Shipping and handing
FEDEX is our preferred shipping method. We offer ship goods with EMS TNT DHL and UPS.
Insurance
Buyers are responsible for any insurance they feel is required..
RefundExchange Only
If you are not satisfied with your purchase, you can exchange the item. The buyer is responsible for all further shipping fees.2. The buyer must contact us within 3 days of delivery if they wish to exchange defective or incorrectly shipped items.
Feedback
Please contact us before leaving any negative or neutral feedback. We will work with you to solve any problems.
Service:
pre-sale, sale and after-sale tracking service is comprehensive, The first-class technical team, providing technical support, complete and spotless quality guarantee.
