YTP-460R2C Specification:
Printing Station |
2sets |
Gearing |
1/8* |
Max.paper width |
460 mm |
Max.printing width |
450 mm |
Unwind roll dia.max |
600 mm |
Rewind roll dia.max |
600 mm |
Max printing length |
460.375 mm |
Min printing length |
190.5 mm |
Max printing speed |
100 m/min |
Net weight |
2000 (kgs) |
Gross weight |
2500 (kgs) |
Main motor |
4.0 380v(kw) |
Stirring motor(2pcs) |
400 w |
UV dryer 2 sets |
10 kw |
Machine size |
3*1.6*1.6 m |
Standard Accessorise:
Printing station |
2 sets |
Printing cylinder(Size Optional) |
5 sets |
UV dryer |
2 sets |
Tools |
1 set |
Block setting table |
1 set |
Automatic web guiding system |
1 set |
Splicing platform |
1 set |
Corona treater (Foil can be treated) |
|
Electrostatic Eliminator |
The Selects and Purchases Equipments:
Intaglio plate printing system
Suitable material:Adhesive paper,Laminate material BOPP Film,Shrinkable Film Styrofoam and other special material.
Standard plate making reference:photopolymer plate
Plate hardness:45°~55°
Plate thickness:0.95mm
Depth:0.69mm(reference)
