One Channel ECG Machine, Portable Ecg Machine

UM020901

ECG Machine, One Channel

Lead: Standard 12 lead

Input Impedance: ≥50MΩ

Input Circuit Current: ≤50nA

Calibrating Voltage: 1mV±3%

Skin Voltage Tolerance: ±300mV

Sensitivity: 5, 10, 20mm/mV

Time Constant: ≥3.2s(0,+20%)

Sampling Rate: 1ms

Product Display

UM020902

ECG Machine, Three Channel

Lead: Standard 12 lead

Input Impedance: ≥50MΩ

Input Circuit Current: ≤50nA

Calibrating Voltage: 1mV±3%

Skin Voltage Tolerance: ±300mV

Sensitivity: 5, 10, 20mm/mV

Time Constant: ≥3.2s(0,+20%)

Sampling Rate: 1.25ms

UM020903

ECG Machine, Twelve Channel

Lead: Standard 12 lead

Input Impedance: ≥50MΩ

Input Circuit Current: ≤50nA

Calibrating Voltage: 1mV±3%

Skin Voltage Tolerance: ±300mV

Sensitivity: 5, 10, 20mm/mV

Time Constant: ≥3.2s(0,+20%)

Sampling Rate: 1.25ms
