rebar tying machine xdl400

rebar tying machine xdl400

• Specifications of RT-580 450 280 machines

  Model	RT-580	RT-280	RT-450
  Applicable Rebar Size	12-65 mm	4-28 mm	6-40 mm
  Wraps per knot	3-4 wraps	2-3 wraps	2-3 wraps
  Ties per charger	2500 knots	3300 knots	2700 knots
  Ties per roll of wire	90-78 knots	230-170 knots	170-120 knots
  Wire length per tying	103-128 cm	43-58 cm	60-82 cm
  Machine Size	31.5*30.5*10.5cm	28*30*10.5 cm	30*30*10.5cm
  Machine Net Weight	2.8 Kg	2.7 Kg	2.7 Kg
  Battery Type	Li-ion	Li-ion	Li-ion
  Charging Time	70 minutes	70 minutes	70 minutes
  Wire diameter	0.8 mm	0.8 mm	0.8 mm
  Length per coil	100 m	100 m	100 m
  Weight per coil	0.40 Kg	0.40 Kg	0.40 Kg
  Pack per box	2 pcs	2 pcs	2 pcs
  Charger per box	1 pcs	1 pcs	1 pcs
  Package size	48.5*13.5*38.5 cm	48.5.*13.5*38.5 cm	48.5*13.5*38.5 cm
  Package weight	7.70 Kg	7.65 Kg	7.65Kg

  1.one year warranty for the machine with CE certificate

  2.One set package includes: one machine two pcs batteries  one charger one user manual one pliers four rolls of wire coils one plastic box one gift box

  3.The package: after plastic box is a small carton then 3 or 2 pcs into a big carton.

  • REDUCES TYING TIME
    5 times faster than manual tying. Makes ties in less than 1sec. per tie with consistent tie strength. High speed tying saves you time and money.
  • LI-ION HIGHER CAPACITY BATTERY
    Thanks to the Lithium-lon battery technology the RT450 ties approx. 3000 ties per charge which is 6 times more than Ni-Cd model. Less charging time means more productive work on the jobsites. Also Lithium-Ion battery has no Memory Effect so you can charge the battery whenever convenient
  • BRUSHLESS TWISTING MOTOR
    The brushless electric motor offers higher efficiency and longer life. It increases ties per charge by 35% comparing with older model motor and does not require service caused by brush erosion or dirt on commutator.
  • LIGHT WEIGHT & COMPACT BODY
    Weighs only 5.2lbs Easy to handle.
  • ONE HAND OPERATION
    Allows worker to hold re-bar while tying reducing set up time.

  RFQ



  1. Q: Are you a factory or a trading company ?

  A: We are a factory.



  2. Q: Can you provide samples ?

  A:yes we are able to offer  samples.



  3.Q: How can I have a Proforma Invioce/Quotation?

  A: You can have Proforma Invoice/Quotation either by providing us the list of your requirements through fax email or by sending an enquiry.



  4.Q: What options do I have for paying the freight charges?

  A: We make the Proforma Invoice as per the clients’instructions like FOB & EXW.



  5.Q: What are your payment terms?

  A: All payments should be made in US dollarsunless specified in the quotation sent to you.









  NINGBO KOWY INDUSTRY LIMITED

  Website:

  Tel: +86-574-65222229

  Fax: +86-574-65537957

  Add: No.1 Ningxing Road Yuelong Street Ninghai County Ningbo City Zhejiang Province China
