Specifications
excellent PET bottle crushing machine1.Stable running
2.Durable parts
3.Efficient production
excellent PET bottle crushing machine
Function: Crush PET bottle to flakes of certain size (size controlled by sieve)
Model: 500# /600# /700# /900#/1000# /1200# /1500#
Capacity: 500KG-3000KG/H
This type of high-performance PE/PP crushing machine developed by GrnWell have following features:
1. Both dry and wet crushing availible. Wet crushing have good affect of washing.
2. Crushing chamber specialy designed for bottles, which featured by fast feeding, preveting material from jam and bounce, no repeat cutting, and the output flakes is even and less powder.
3. Specially designed shaft Angle of rotary knife, forming the most energy saving, quiet cutting Angle,. The output load is stable and vibration is small, effective increase the efficient powwe and extent the service life of the transmission system and structural.
4. Structure of flip-open cover provide safe, fast and convinient maintainence and shorten half of the mmiantaining hours.
5. Main shaft installed external of the machine, which is easy to maintain and not affect by temperature and fleak of the machine, extent the using life.
6. The structure and operation safty of the machine meet the CE standard.
7. The blade adopt high quality material and strictly heating processing, ensure the durability of baldes.
Principles:
Through shearing force produced by movable blade and fixed blade to crush materials into pieces. Size of finished product depends on size of the crusher’s screen aperture.
| Model Forcible Feeding Type | GW700B | GW900B | GW1200B | |
| Outer Spec | Machine dimensions | 2.0*1.5*2.1m | 2*1.9*2.4m | 2.3*2.0*2.7m |
| Weight of machine | 1920kg | 3100kg | 5000kg | |
| Inner Spec | rotate speed | 460 r/m | 430 r/m | 300 r/m |
| Power | 33 Kw | 50.5 Kw | 62.5 Kw | |
| Voltage | Customized | |||
| Frequency | Customized | |||
| Blade | 10pcs | 10pcs | 20pcs | |
| Performance | Capacity | 1000Kg /hour | 2000kg/hour | 3000kg/hour |
| Feeding method | forced feed | forced feed | forced feed | |
| Flakes size | Customized, screen size 16-40 mm | |||
| Remark | Above model all equiped with Hydraumatic Spindle workstation which convinience for turn over the crushing chamber for replacement of blade. | |||
| Service | After-sales Service Provided: Engineers available to service machinery | |||
Packaging Detail:
Export standard,nude packing in container.if client have requirement,we can use wooden case.
Transportation:
1. These machines are processed to be rustproof and moisture proof before delivery.
2. Large mainframes are in nude, while small spare parts and motors are in wooden boxes.
3. All items are in bulk or containers, details will be negotiated by both parts afterwards.
We can not only provide the good machines, but also wholeheartedly provide the comprehensive for our clients. The series of professional technology service will make you have an excellent product experience.
Pre-sales Service:
The wide product range enables us to provide our customers with stand-alone machines or complete processing plants. Based on our customers’ request and budget, our experts make efficient, reliable solutions. Following customers’ order we produce strictly, To ease the trip for every visitor to our factory, we provide all relevant visitor-friendly services including invitation letter preparation, hotel reservation, airport pick-up, incity transportation, and sightseeing guide, etc.
After-sales Service:
Experienced technicians guidance is available on the phone, and on the internet. One or more engineers will be dispatched to the quarry site to help install the customers’ plants. Necessary training about machine daily maintenance to local workers is provided also. After-Sales department is made of well-trained employees and installation engineers, the installation engineers are special and professional members of GrnWell, they are strategically located home and abroad, working for our customers.
GrnWe is specialized in researching & producing kinds of plastic washing & recycling machines. Grnwe supplies high quality machine and recycling solutions to customers worldwide. Products mainly range from PET bottle recycling line, PET flakes recycling line, HDPE/PS recycling line and PE/PP/PO film recycling line. Benefitting from the design capability and mode of modularity, GrnWe have rich experience in customize and optimize the recycling process according to the raw materials and requirements. Therefore the quality and competitiveness of recycled materials have been significantly improved.
GrnWe is one of your ideal partners in the field of plastic recycling, from beginning of the negotiation to seeking for best solutions, and from machinery manufacturing to after-sales service. Reliable quality, rich experience, professional technology and environmentally friendly, Grenfell’s solution is always profitable choice for customers, market and the environment.
How about the quality of our machine?
Our machine manufactured strictly according to national and international standard.
We take a test on every machine before delivery.
How about price of machine?
We can give the lowest price than market one.
We do quotation of machine as soon as possible for any custome.
Discount of machine can be given according to quantity.
How about the after-sale service of your company?
Our engineer is aviliable to installation machine overseas.
The guarantee period of our machine is one year.
Spare parts will supply at any time.
