transmission line fitting vibration damper,vibration damper
Brand:Shandong Haihong
Composition: hot galvanized casting iron hammer, hot galvanized steel twisted wire, aluminum
alloy clamp, stainless steel bolts.
Purposes: to eliminate or reduce the vibration when the fiber optic cable operate under the influence of kinds of factor, then protection of cables and fittings.
Features: using a typical Harrow design, the basic principles : dynamic absorbing energy, frequency protection range from 6Hz to 150Hz, and in this range it has four resonant frequencies.
Technical requirements: comply with GB / T 2336-2000 anti-vibration hammer technological conditions.
Order Information: Users must provide the following information for specific projects the company can make corresponding vibration programs:
a. line tower schedule.
b. topography, landforms (plains, hills, mountains, forests, across rivers).
c. Cable specification model and relevant parameters - diameter (mm), nominal tensile strength (N), unit weight (kg / m) and so on.
Damper Specifications Model and Parameter table:
Model |
Aluminum clip Specifications |
Clamping range (mm) |
Total length (mm) |
Clamp Length(mm) |
Clamp Height (mm) |
Quality (kg) |
4D30 |
27 |
27.0-22.5 |
383 |
52 |
70 |
2.5 |
23.4 |
23.4-19.5 |
72 |
||||
20.3 |
20.3-16.5 |
73 |
||||
4D20 |
23.4 |
23.4-19.5 |
330 |
52 |
72 |
1.4 |
20.3 |
20.3-16.5 |
73 |
||||
18 |
18.0-15.0 |
65 |
||||
4D10 |
18 |
18.0-15.0 |
|
|
65 |
1.0 |
16 |
16.0-13.3 |
63 |
||||
14 |
14.0-12.2 |
62 |
||||
Note: 4D10, 4D20, 4D30-type anti-vibration hammer in accordance with applicable cable diameter and select the appropriate size of the aluminum clip. | ||||||
Armor rod for anti-vibration hammer: In order to avoid the damage when anti-vibration hammer clamp gripping the OPGW cable, coupled with aluminum alloy armor rod, protection cable, at the same time the system play a role in anti-vibration .
Specifications Model representation: HXT-Length (mm )-**.
**-- On behalf of Cable diameter (mm).
