Electronics for 3D Printer Mainborad for Wanhao 3d Printer
US$ 110 - 128
MOQ: 1 Pair
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
wanhao
Model Number:
mother board
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Timing Belt for WANHAO 3d Printer Dupalicator 6 D6-606-2GT-6 as Spare PartsUS$ 5 - 6.5MOQ: 1 Piece -
Stop Switch Line for WANHAO D5S, D5S Mini as Spare Part for 3d PrinterUS$ 1.99 - 2.99MOQ: 1 Piece
-
D5S, D5S Mini Motherboard, Mainboard for WANHAO 3D FDM PrinterUS$ 160 - 180MOQ: 1 Piece
-
Wanhao Dupalicator 4S Platform Liner Bearing as Spare Parts for ReplacementUS$ 12 - 15MOQ: 2 Pieces
-
WANHAO Duplicator I3 MK10 Hot End Extruder for ReplacementUS$ 45 - 48MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
wanhao
Model Number
mother board
Type
Main Board
Use
Other, 3d printer
Printing Type
Screen Printing Machine
wanhao 3d printer mainboard
Technical Specification For mainbord
| Number of Layer | 1,2,4 or 6,upto 18 layer |
| Order Quantity | 1 to 50,000 |
| Board Shape | Retangular,round,slots,cutouts,complex,irregular |
| Board Type | Rigid, Flexible, Rigid-flexible |
| Board Material | FR-4 glass epoxy, FR-4 high Tg, Rohs compliant,Aluminum,Rogers,etc. |
| Board Cutting | Shear,V-score,Tab-routed |
| Board Thickness | 0.2-4.0mm, Flex 0.01-0.25mm |
| Copper Weight | 1.0, 1.5, 2.0 oz |
| Solder Mask | Double-sided green LPI,Also support Red,White,Yellow,Blue,Black |
| Silk Screen | Double-sided or single-sided in white,yellow,black,or negative |
| Silk Screen Min Line Width | 0.006'' or 0.15mm |
| Max Board Dimensions | 20 inch*20inch or 500mm*500mm |
| Min Trace/Gap | 0.10mm, or 4mils |
| Min Drill Hole Diameter | 0.01'',0.25mm, or 10mils |
| Surface Finish | HASL,Nickle,Immersion Gold,Immersion Tin,Immersion Silver,OSP,etc. |
| Board Thickness Tolerance | ±10% |
| Copper Weight Tolerance | ± 0.25 oz |
| Minimal Slot Width | 0.12'', 3.0mm, or 120mils |
| V-Score Depth | 20-25% of board thickness |
| Design File Formate | Gerber RS-274,274D,Eagle and AutoCAD's DXF,DWG |
Assembly Capabilities
| Quantity | Prototype&Low Volume PCB Assembly,from 1 Board to 250,is specialty,or up to 1000 |
| Type of Assembly | SMT,Thru-hole |
| Solder Type | Water Soluble Solder Paste,Leaded and Lead-Free |
| Components |
Passive Down to 0201 size BGA and VFBGA Leadless Chip Carriers/CSP Double-sided SMT Assembly Fine Pitch to 0.8mils BGA Repair and Reball Part Removal and Replacement |
| Bare Board Size |
Smallest:0.25*0.25 inches Largest:20*20 inches |
| File Formate |
Bill of Materials Gerber files Pick-N-Place file |
| Types of Service | Turn-key,partial turn-key or consignment |
| Component packaging | Cut Tape,Tube,Reels,Loose Parts |
