Specifications
1) High pressure vacuum laminating machine
2) Best quality
3) Customized
Touch Screen LCD Glass OCA Lamination Machine for Repairing iPhone 4 4S 5 iPad Samsung Sony HTC
This vacuum laminating machine does not need air compressor, vacuump pump, and has built-in bubble remover.
Machine technicals:
Machine driver:AC220V 1500W
Optional for AC110V /AC220V
Working environment:20-30℃,clean and dustfree.
Lamination way:Flat-plate lamination type
Efficiency:90s/1pcs(Separated lamination type),1H/80pcs(defoaming assisted type)
Heating mode: constant temperature heating
Used size:All below 7"model
Device size:535*425*355mm
Device weight(NT):56.5kg
Device power:800W
Defoaming parameters:
Cavity size:H 180mm,Diameter 120mm(put into 15pcs 7-inch screen one-time)
Working temperature:Suggested set 35°C~45°C(can be adjustable according to different OCA temperature)
Defoaming time:Suggested 8~10 minutes(it is best)
Feature:
*No mould, also can set to be no defoaming or defoaming assisted type to apporve the output.
*No installation,can be working directly when plug in .
*Don't need other auxiliary equipment, such as vacuum pump, air compressor.
*Used standard 6063 aluminum alloy for lamination,durrable, anti-corrosion and no deformation.
*Debubblers cavity materials is 304 15mm stainless steel,safe.
*Fitting and debubblers can be operated simultaneously, improve efficiency.
*The components are imported from Japan.
*Simple one-touch operation.
*Japan temperature control, temperature can be accurate to + / - 1 ℃.
*Intelligent constant pressure, laminating and defoaming mode automatically switch.
*Flat-plate form laminating, stable and even pressure, no bubble, no indentation, easy transportation.
Maintenance:
Maintenance items |
Maintenance notice |
Mold base |
check and clean odds and ends |
Lamination pole and table slide rails |
Oiling into the lamination pole and table slide rails,keep working smoothly.(2-3 month will be better) |
Radiating net |
Keep clean, Non-clogging |
Packaging
Packaging material: wooden box
Packaging weight: 75KG
Shipping
1, 2-5 workdays shipping from China via Air/Commercial express (DHL/FedEx/UPS/EMS etc.)
2, we can arrange shipment via sea. Min CBM requirement: 1 CBM
