oil cooler
- 6000 Piece / Pieces per Month
- Guangzhou/Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
- New Aluminum 15L Capapity air oil cooler for concrete mixer truck
- 12L Capapity air oil cooler for concrete mixer truck
- Standard New Oil Cooler for concrete mixer truck
- Standard Hydraulic Oil Cooler for Concrete Mixer Truck
- Aluminum Plate and Bar Hydraulic Oil Cooler for Concrete Mixer Truck
- Hydraulic Oil Cooler for Concrete Mixer Truck
Product Details
Condition: | New | Place of Origin: | Guangdong, China | Brand Name: | Alliance |
Model Number: | EATB50-66 | Structure: | Plate Heat Exchanger | Liquid Flow Rate: | 450L/M |
Maximum Working Pressure: | 3.0MPa | Voltage: | available | Weight: | 19kg |
Dimension(L*W*H): | 539mm*125mm*190mm | Power(W): | 112kw | Certification: | CCC, CE, ROHS, UL, Other, CCC, CE, ROHS, UL, ISO9001 |
Warranty: | 15 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
oil cooler | |
Series | EATB50 |
Design pressure(Mpa) | 1.0 OR 3.0 |
Lowest working temperature | -180 |
Hightest working temperture | 200 |
Heat transfer area per plate | 0.062 |
Volume per channal(L) | 0.14 |
Cross-sectional area per channal | 0.0003 |
Plate material | SS316L/304L |
Welding material | 99.9% COPPER |
Height(mm) | 539 |
Width(mm) | 125 |
Thickness(mm) | 2.762×N(number of plates)+8 |
Weight(Kg) | 0.25×N(number of plates)+3 |
1,Used in various fluid media:all type of refrigerants(R410a,R407c,R404,R134a,R22,R23,etc),oil,water,water and glycol mixtures.
2,Used in various equipment:hot pumps,industrial water cooling machines,plastic injecting machines,welding machines,oil pressure machines,compressors(circulation oil),air conditioners,refrigerators,air dryer,water cooler,drinking thoughts,constant temperture refrigerator,heat recollection and circulation,floor heating,indoors and outdoors heating devices
How oil cooler Works: |
Heat transfer occurs when there is a difference in temperature between two mediums. Heat will travel from the hot source to the cold source. The rate at which the heat transfer occurs at is determined by many factors such as the heat conductivity of the two materials andthe difference in temperatures of the two mediums. Convectiuve heat transfer occurs when the materials are moving against each other |
Corrosion protection for oil cooler stainless steel has a high resistance to most chemicals but is sensitive to chloride ion concentration so this must be limited to 280ppm or less(lower than 55 C),the copper used in the brazing process is mainly sensitive to strong acid and ammonia so the PH must be maintained between 6 to 8.in practical application.for example,hydrochloric acid should never be used to clean the oil cooler ;if oil cooler are applied in seimming pool heating,limite chloride ion concentration to 280ppm in the water;what's more,in chemical,pharmacy and other industries,solutions containing strong acid like hydrochloric acid and harshorn won't be proper fluid medium. |
Applications for the oil cooler : |
This is an extremely popular unit for wood burning furnaces, radiant floor systems, refrigerant systems, straight vegetable oil conversions, beer chilling, air conditioning system and solar water heating systems. It will work for any application in which the desired result is for two fluids (liquid or gas) to exchange heat. |
East-Alliance Thermal Equipment Co.,Ltd, a HK-funded enterprise located in Chaoyang Industrial Zone of Jiangmen City in Guangdong Province,China,belong to Guangdong DongXu Group. The Company has been specializing in brazed plate heat exchangers manufacture and sales, which are widely applied to the fields involved in cooling, heating, oil pressure, vessel, electric power, paper making, metallurgy.etc. |
The company possesses a complete set of professional production and detection equipments such as the stamping equipment, the vacuum brazing furnace and the high-vacuum helium leak detector, etc. Our mold design and development as well as the plate exchanger technology and application had achieved an international leading level. |
As a Guangdong Province private technology enterprises,the products have complete independent intellectual property rights, Obtained many the national invention patents , obtained the national technological innovation fund specialized to science and technology enterprises.It has been manufaturing high quality products with imported stainless steel by the most advanced vacuum welding furnace ensuring the first grade quality. |
The company has been constantly carrying out the Quality Managenment System Standard of ISO9001:2000 and had passed the PED/CE and Rosh Certification to export to EU,by means of our high quality and elaborate products together with our professional and fast service,we are dedicated to satisfying the needs of all our clients worldwide |
