Help CenterHT-630F Double Motorised Pay-off Stand
Related Products
-
Take-up(pay-off) Cable MachineNegotiableMOQ: 1 Set -
Wire Pay-off MachineNegotiableMOQ: 1 Set
-
Pay-off and Take-up Machine for Wire Drawing( Factory Price )NegotiableMOQ: 1 Set
-
Pay-off MachineNegotiableMOQ: 1 Set
-
High Efficiency & Speed ( Take-up Machine ) Motorised Pay-offNegotiableMOQ: 1 Set
Specifications
Applicable bobbin: Max. 630mm plastic bobbins / steel bobbins1. HT-630F double motorised pay-off
Applicable bobbin Max. 630mm plastic bobbins / steel bobin (drawings shall be offered by users)
Bore Dia. of bobbin 127mm
Bobbin weight after loading wire less than and equal to 400KGS
Control 2HP digital inverter + AC motor drive
Max. speed 200m/min
Traverse follow the wires on bobbins;
Tension control by air automatically;
Transmission part the main drive motor with speed reducer.
Shafts material 40CrMn,
Machine body made of steel plates (Q235A) by welding, through annealing to eliminate
internal stress and then processed by precision milling machine.
