FP360 is used for parking pick-up trucks and equivalent vehicles. The standard lifting capacity is 3600kgs.
With the unique tire protect side beam design, the driver doesn't need to worry about running off the platform by mistake anymore.
In the center of the platform, it is covered by 4 pieces of removable diamond plate. The user can easily take them off and turn the lift from a parking lift into a service lift instantly.
l 3600KGS Lifting Capacity For Any SUVs and Regular Pick-up Trucks
l Easy Installation (Referenced Man Hour, Two Skilled Workers For 5 Hours)
l Easy Relocation
l Different Parking Heights
l Full Range Dynamic Anti-Fall Locks
l Emergency Stop Button
l Safety Key Switch Controller
l Tier Protected Side Beam Design To Prevent From Running off the Platform By Mistake
l Automated Locking Detection
l Hydraulic Cylinder Protection
l Hydraulic Overload Protection
l Anti-Skid Ramp and Platform
Vehicle Transport System (VTS) is also recognized as a platform lift. It is ideally suitable for the applications where vehicles needs to be transferred among different building floors for car display or car storage. The product can be used for the goods or items transport alternatively as well. There are scissor type S-VTS and four type F-VTS. And both of them are hydraulic driven. VTS is a totally customized car lifting system. We design the system, including lifting height, weight and parking platform, fully based on the customer’s requirements.
FP360 Four Post Parking lifts are warranted for 10 years on structural parts such as columns, platforms, carriages and so on, and 3 years for non-structural parts like power pack and electrical parts etc. The warranty is effective immediately from the date the invoice is issued. In the warranty period, Solid Parking shall replace those parts returned to the factory which prove to be defective. This warranty shall not apply unless the product is installed, operated, used and maintained in accordance with the instructions from Solid Parking. Solid Parking reserves the rights to change the terms without further notice.
Steel frame with plastic wrap cover.
20ft:12Units
40ft:24 Units
Pre-sales Service
Fast Email Response
Full Technical Support
Free Drawing Service
Financing Service
After-Sales Service
Production Progress Report
Inspection Report
Shipping Report
Installation & Maintenance Support
As the brand for parking products, Solid Parking has been providing OEM service to oversea parking companies for years. We are committed and dedicated to continually supply the most reliable and cost-efficient parking systems and related products to our customers.
We are specialized on two post car stackers, four post car stackers, pit parking lifts, multi-level parking lifts, vehicle transport platform lifts, and automatic parking systems.
In order to guarantee the quality, our production has adopted the most advanced technology including laser cutting and robotic welding process. All of our products are CE certified. The products are designed and manufactured for long-term heavy duty use.
Our industry:Chunfeng Industrial Group Co., Ltd. is the one of the largest machinery manufacturers in China.We have over 400 employees including 42 experienced engineers. The annual production volume of parking equipment is about 20,000 parking spaces.
Q1:How many years warranty of Solid Parking series products?
A1:All of our products have 15-year main structure warranty and 1 year parts warranty.Now some of our products even have 2 year parts warranty.
Q2:Can Solid Parking products be used outdoor?
A2:Yes,all of our products are capable for both indoor and outdoor.The finishing is power coating and the platform cover is galvanized, with rust-proof and rain-proof.When you use outdoor, you should consider the ceiling height.
Q3:Is the operation easy?
A3:Yes,keep holding the key switch to operate equipment,which will stop at once if your hand release the key switch.
Q4:Can this kind of equipment still operate if the electricity failure?
A4:Yes,the platform can be descended even if there is no electricity. Firstly,you need manually keep two electromagnetic lock retrieve to release the mechanical anti-falling,meanwhile the solenoid value on the power unit can be opened manually to make hydraulic oil go back to oil tank, then the platform will descended by gravity.
Q5:What’s the supply voltage?
A5:Standard voltage is 220V,50-60Hz 1 phase,Other voltage can be customized according to client request.
