Help CenterCoating Usage High Quality Wire Coating Equipment ( Sn, Ag, Ni, Zn )
Related Products
-
10000A Tin-on-copper Wire Electrolytic Plating Machine and LineNegotiableMOQ: 1 Set -
5000A Nickle-on-copper Wire Electrolytic Plating Machine and LineNegotiableMOQ: 1 Set
-
5000A Zinc (Zn)-on Copper and Copper Alloy Wire Electrolytic Plating Machine and LineNegotiableMOQ: 1 Set
-
3000A Silver (Ag)-on-copper Wire Electrolytic Plating Machine and LineNegotiableMOQ: 1 Set
-
6000A Tin (Sn)-on-copper Wire Electrolytic Plating Machine and LineNegotiableMOQ: 1 Set
This series of wire electrolytic plating machines and production lines (Tin-plating, Nickle-plating, Zinc-plating, Silver-plating) are used to plating the Tin, Nickle, Zinc or Silver of thickness between 1 to 60 μm on copper wires of diameter between 0.80 to 2.60 mm. Other equipments, i.e. drawing machines, annealers, pay-offs and take-ups, are also available to compose a complete production line for coated wire cable production. For any special requirements, you may contact us directly for further confirmation.
- This line can be in tandem with a rod breakdown machine with annealer to produce tinned copper wires.
- This line has advantages of high production capacity, high quality and low power consumption.
- With strong controllability of tin thickness and uniformity.
- The utilization rate of tin can reach to 98%.
- Equipped with the most advanced online exhaust and waste water treatment system to ensure the water quality after treatment can meet international environmental standards, so that it can achieve zero discharge and zero pollution in production process.
- High degree of automaticity.
- All parameters setting are controlled via computer program.
- Easy operation. Save labor. Lower costs.
We have a series of wire electrolytic plating machines and production lines of this kind to satisfy your diversified demands. You can always find what you prefer:
DESCRIPTION |
WIRE ELECTROLYTIC PLATING LINES |
||||
HT MODEL NO. |
HT-10000Sn.15m/s |
HT-6000Sn.15m/s |
HT-5000Ni.5m/s |
HT-5000Zn.15m/s |
HT-3000Ag.10m/s |
MATERIAL |
Cu+Sn |
Cu+Sn |
Cu+Ni |
Cu, Cu alloy+Zn |
Cu+Ag |
MACHINE SPEED |
15m/s |
15m/s |
5m/s |
15m/s |
10m/s |
NO. OF WIRES |
1 |
1 |
1 |
1 |
1 |
WIRE RANGE |
1.20~2.60mm |
1.00~2.60mm |
0.80~2.60mm |
0.80~2.60mm |
0.90~2.60mm |
COATING THICKNESS |
1~25μm |
1~20μm |
1~60μm |
1~60μm |
1~20μm |
PLATING CURRENT |
10000A max. |
6000A max. |
5000A max. |
5000A max. |
3000A max. |
PAY-OFF TYPE |
in tandem with a drawing machine / bobbin type pay-off / basket type pay-off |
||||
TAKE-UP TYPE2 |
HT-650C Down coiler |
||||
LINE DIMENSION |
8000*6000*2600mm |
||||
Power Supply
^ 3-phase voltage ~3×380VAC (±10%)
^ Single-phase voltage ~220VAC (±10%)
^ Frequency 50Hz (±2%)
Note: This is an important factor affecting price. If the power supply in your country or region is different from our system, please advise us in your inquiry.
We provide you complete range of wire drawing equipment and comprehensive wire drawing solutions.
|
|
|
|
|
|
Copper Rod Breakdown Aluminum Rod Breakdown Individual Drive Rod Breakdown |
Multi-Wire Drawing 4-wire, 8-wire, 16-wire |
Medium Wire Drawing Large-Medium Wire Drawing |
Copper Fine Wire Drawing With Annealer With Double Spooler Aluminum Fine Drawer |
Electroplating Sn, Ag, Ni, Zn |
|
|
|
|
|
|
Annealing & Tinning
|
Twist Bunching 500P, 630P, 800P, 1000P, 1250P |
Spooling & Coiling Spooler: Compact, Single, Dual Basket Down Coiler |
Motorised Wire Pay-Off |
Auxiliaries Cold Welder, Powder Filter Pointing, Coil Packing, Spool, Bobbin, Reel
|
Jiangsu Honta Machinery Co., Ltd. (factory) or Kunshan City Hongtai Machinery & Electric Equipment Co., Ltd. (export company) is a renowned cable equipment manufacturer in China, specialized in the research, design and making of wire drawing machines and other auxiliary equipment.
We make a full coverage of wire drawing machines and equipment to satisfy your diversified demands in cable and wire production.
Our products covers:
- Rod break down drawing machines and lines
- Large and medium wire drawing machines and lines
- Fine and superfine wire drawing machines and lines
- Tinning and other electroplating lines
- Twisting and bunching machines
- Spooling and coiling machines
- Other auxiliaries
Among them are the most hot-sale items:
- Rod break down drawing machine (for producing copper and aluminum wires) is one of our most welcomed products in our sales list with its high automaticity and high efficiency.
- Multi-wire drawing machine (including 16-wire, 8-wire and 4-wire models) is another one of our most favored products on the market with most advanced technology and convenient operation, which multiplies our customers’ productivity in copper wire production and bring multiple profits to them.
Our products are user-friendly and easy-to-use, which saves you a lot of labor and money in operation and maintenance.
Customers from around the world, including Russia, Japan, Brazil, Iran, Turkey, India, and many other countries are using our products and enjoying our service.
Welcome to visit our company!
<tags: wire drawing machine, Drahtziehmaschine, Trefilas, trefiladoras, machine à tréfiler >
Our MACHINES or PRODUCTION LINES are well packed on steel pallets in containers, suitable for long distance ocean freight transportation and the change of climate, and well protected against moisture and shocks.
