Help CenterStrander Stranding Machine Cable Machine
Related Products
-
High Speed Double Twist Bunching MachineNegotiableMOQ: 1 Set -
Double Twist Bunching MachineNegotiableMOQ: 1 Set
-
650P Wire Double Twist Bunching Machine, China Machinery Manufacturers, Build Coil WinderNegotiableMOQ: 1 Set
-
Double Twist Bunching Machine High Speed Electric Copper Wire Making EquipmentNegotiableMOQ: 1 Set
-
Double Twist Bunching Machine High Speed Electric Twisting Machine Copper Wire Cable Making EquipmentNegotiableMOQ: 1 Set
Specifications
high speed, high efficiencyProduct Information
1)Machine Type: HT-630P
2)Diameter Of single wire(mm): Cu Φ1.5~Φ4.5
Al alloy Φ1.8~Φ4.5
Al Φ1.8~5.0
3)Rotating speed of cages: 99.8-174.7rpm for 6-B cage
89.8-157.1rpm for 12-B cage
76.4-133.7rpm for 18-B cage
4)Stranding pitch: 40-531mm for 6-B cage
44-590mm for 12-B cage
52-694mm for 18-B cage
5)Line speed: 6.9-53m/min(36-step gear box for capstan)
6)Main motor: 110kw
7)Payoff reel in the cage(mm): 630
8)Dual wheel capstan size: dia. 2000mm(dual driven)
9)Take-up reel (mm): 1600~2500
10)Max. load of take-up: 12T
11)Bobbin loading/unloading: Side loading simultaneously
12)Central payoff reel (mm): 2000
13)Center height(mm): 1100
14)Operating direction: From left to right
