Help CenterAnnealing Usage Aluminum and Copper Wire Annealing Machine
Related Products
Annealing machine for aluminium rod breakdown drawing line
Annealing machine for copper rod breakdown drawing line
Annealing machine for medium wire drawing line
- The horizontal and tandem construction.
- High efficiency. Low noise.
- DC/AC annealing control, speed tracks to drawing speed automatically, which ensures uniform and stable elongation of aluminium wires.
- The line is an equipment of high automaticity and high efficiency.
We have a series of annealers (annealing machines) to equip with copper or aluminum rod breakdown machines, medium wire drawing machines and fine wire drawing machines. You can choose them to work with your existing drawing line for quality improvement or line upgrade:
Machine type |
HT-5000 |
HT-6000 |
HT-8000 |
HTA-4000 |
Material |
Cu, Cu alloy |
Cu, Cu alloy |
Cu, Cu alloy |
Al, Al alloy |
Max Machine Speed (m/min) |
1500 |
1500 |
1500 |
1500 |
Number of wires |
1 |
1 |
2 |
1 |
Wire range (mm) |
1.20~3.50 |
1.20~4.00 |
1.20~3.50 |
1.60~4.50 |
Contact pulley diameter (mm) |
355 |
450 |
450 |
450 |
Max annealing current (A) |
5000 |
6000 |
8000 |
4000 |
Max annealing voltage (V) |
60 |
60 |
60 |
60 |
Control method |
DC |
AC |
AC |
DC |
Power Supply
^ 3-phase voltage ~3×380VAC (±10%)
^ Single-phase voltage ~220VAC (±10%)
^ Frequency 50Hz (±2%)
Note: This is an important factor affecting price. If the power supply in your country or region is different from our system, please advise us in your inquiry.
We provide you complete range of wire drawing equipment and comprehensive wire drawing solutions.
|
|
|
|
|
|
Copper Rod Breakdown Aluminum Rod Breakdown Individual Drive Rod Breakdown |
Multi-Wire Drawing 4-wire, 8-wire, 16-wire |
Medium Wire Drawing Large-Medium Wire Drawing |
Copper Fine Wire Drawing With Annealer With Double Spooler Aluminum Fine Drawer |
Electroplating Sn, Ag, Ni, Zn |
|
|
|
|
|
|
Annealing & Tinning
|
Twist Bunching 500P, 630P, 800P, 1000P, 1250P |
Spooling & Coiling Spooler: Compact, Single, Dual Basket Down Coiler |
Motorised Wire Pay-Off |
Auxiliaries Cold Welder, Powder Filter Pointing, Coil Packing, Spool, Bobbin, Reel
|
This MACHINE or PRODUCTION LINE that you ordered will be well packed on steel pallets in containers, suitable for long distance ocean freight transportation and the change of climate, and well protected against moisture and shocks.
Jiangsu Honta Machinery Co., Ltd. (factory) or Kunshan City Hongtai Machinery & Electric Equipment Co., Ltd. (export company) is a renowned cable equipment manufacturer in China, specialized in the research, design and making of wire drawing machines and other auxiliary equipment.
We make a full coverage of wire drawing machines and equipment to satisfy your diversified demands in cable and wire production.
Our products covers:
- Rod break down drawing machines and lines
- Large and medium wire drawing machines and lines
- Fine and superfine wire drawing machines and lines
- Tinning and other electroplating lines
- Twisting and bunching machines
- Spooling and coiling machines
- Other auxiliaries
Among them are the most hot-sale items:
- Rod break down drawing machine (for producing copper and aluminum wires) is one of our most welcomed products in our sales list with its high automaticity and high efficiency.
- Multi-wire drawing machine (including 16-wire, 8-wire and 4-wire models) is another one of our most favored products on the market with most advanced technology and convenient operation, which multiplies our customers’ productivity in copper wire production and bring multiple profits to them.
Our products are user-friendly and easy-to-use, which saves you a lot of labor and money in operation and maintenance.
Customers from around the world, including Russia, Japan, Brazil, Iran, Turkey, India, and many other countries are using our products and enjoying our service.
Welcome to visit our company!
