LPV--12 series single output type 12v led driver constant voltage waterproof switching power supply 12W
LED waterproof switching power supply, metal shell, IP44 ~ IP67 degree of protection can be used for indoor and
outdoor environment.
Built-in active power factor correction function(active PFC),more than 90% efficiency,universal ac input voltage range,possess complete protection.
LPV-12W series LED constant voltage waterproof switching power supply feature:
· Constant voltage style power supply
· Universal AC input range
· Small volume,low weight,high efficiency
· Protections: short circuit/over load/over voltage
· Cooling by free air convection
· Fully encapsulated with IP67 level
· 100% full load burn-in test
Model |
LPV-12-12 |
LPV-12-24 |
LPV-12-36 |
|
|
Output
|
DC voltage |
12V |
24V |
36V |
Voltage tolerance |
±1% |
±1% |
±1% |
|
Rated current |
1A |
0.5A |
0.33A |
|
Current range |
0~1A |
0~0.5A |
0~0.33A |
|
Rated power |
12W |
12W |
11.9W |
|
Ripple & noise |
120mvp-p |
150mvp-p |
150mvp-p |
|
|
Input
|
Voltage range |
170~264VAC, 235~373VDC |
||
Frequency |
47~63HZ |
|||
AC current |
0.1A/230VAC |
|||
Efficiency |
78% |
80% |
82% |
|
Inrush current |
Cold start current 30A/230VAC |
|||
Leakage current |
< 0.5mA/240VAC |
|||
|
Protection
|
Over load
|
105 ~ 135% rated output power |
||
Protection type: Hiccup mode, auto-recovery after fault condition is removed. | ||||
|
Over voltage
|
15.6~17.8V |
30.6~33.2V |
42.6~44.2V |
|
Protection type: Hiccup mode, auto-recovery after fault condition is removed. | ||||
|
Environment
|
Working temp,humidity |
-10°C~+60°C, 20%~90%RH |
||
Storage temp,humidity |
-20°C~+85°C, 10%~95%RH non-condensing |
|||
Withstand vibration |
10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes |
|||
|
Safety
|
Withstand voltage |
I/P-O/P:1.5KVAC, I/P-FG:1.5KVAC, O/P-FG:0.5KVAC |
||
Isolation resistance |
I/P-O/P, I/P-FG, O/P-FG: 100M ohms/500VDC |
|||
|
Fit standard
|
Safety standard |
Fit UL1012, IP67 protect level |
||
EMC standard |
Fit EN55022, CLASSA |
|||
|
Others
|
Dimension |
132*30*20mm(L*W*H) |
||
Weight/packing |
0.15kg/100pcs/16kg/0.027m3/0.94CUFT |
|||
Q 1. what's the payment terms?
Q 2. how's the delivery time ?
A. usually it will take about two weeks for production
Q 3. tell me the standard of package?
A. For the small capacity, it use carton, but for big capacity, we should use strong wooden case for protection.
Q 4. what kind of material of transformer?
A. For servo type stabilizer,we have two types, one 100% copper and the other is copper with aluminum.It depends on your requirment. In fact, those two have no difference if normal work well. Only except the longlife. Copper is better and also higer price.For relay type stabilizer,we use toroid coils, the material is aluminum. comparing with square coils,toriod coils with high efficiency.
Q 5.Could you offer Form A or C/O ?
A. It totally not a problem. We can prepare relative documents to forgin affairs office or other office to apply for this certificate.
Q 6.Would you accept to use our logo ?
A.If you have good quantity,it absolute no problem to do OEM.
Q 7.We want to know month capacity.
A. It depends on which model.For example for relay type small capacity , month capacity can reach near 10000pcs and big capacity near 2000pcs.
Q 8.Where is your market?
A. Our products are popular inNorth America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europeand so on.Some of them are our regular customers and some of them are developing. We hope you can join us and make mutural benifit from our cooperation.
Q 9. what kind of certificate you have ?
A. Our company already achieve ISO9001, and for products, we have CE,PCT,SGS.
