HYM-1500W 12v-230v DC to AC modified sine wave car power inverter

FOB Price

USD $45 - $55 / Piece

500 Pieces(Min.Order)

Supply Ability 10000 Piece / Pieces per Month
Port Shanghai/Ningbo
Payment Terms:T/T Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Zhejiang, China	Brand Name:	GECHY	Model Number:	HYM-1500
Output Power:	1 - 200KW	Output Type:	Single	Size:	32015098mm
Weight:	3KG	Input Voltage:	12V OR 24V DC	Output Voltage:	220VAC/110VAC
Type:	DC/AC Inverters	Output Frequency:	50HZ/60HZ	Output Current:	<0.6A

Product Description

HYM-1500W 12v-230v DC to AC modified sine wave car power inverter

Products Features :

·Small size , light weight and potable

·Easy to use and high efficiency

·Green LED indicates power on,Red LED indicates wrong

·Input & output isolation

·Muti-protection function

·USB output port: 5V 500mA

· Built-in Cooling Fan

Protection Features:

·Low voltage protection

·Over voltage protection

·Overload protection

·Over temperature protection

·Short circuit protection

·Reverse connect protection

Power inverter specifications

Model	HYM1500-121	HYM1500-122	HYM1500-241	HYM1500-242
Output voltage	110V	230V	110V	230V
Input voltage	12V	12V	24V	24V
High Volt Cut off	15-16V		30-32V
Low Volt Alarm	10.5±0.5V		21±1V
Low Volt Cut Off	10±0.5V		20±1V
Rated power	1500W		1500W
Surge power	3000W		3000W
Output frequency	50±2Hz OR 60H±2Hz
USB port	5V 500mA
Output waveform	Modified Sine Wave
No load current	<0.6A
Efficiency	>85%
Max. outer temperature	<65°C
Packing	Gift box
Brand	GECHY or OEM
Certification	CE-EMC/LVD,RoHS, E-mark
Warranty	24 months

Packaging & Shipping

Our Services

1.Enquiry answered within 24 hours
Don't hesitate to send inquiry to us when you see our products, we will do our best to reply as soon as possible and help you get more profit here

2.OEM/ODM available
you can supply your logo and package design to us, we will do that according to your requirements
3.Customized products supplied
we have 2 electronic engineers, so we can produce all kinds of stabilizers according to your thought
4.Sample for you
Telling me your specific address and your requirements of stabilizers, sample can be offered for test before order, but customer will have to pay the sample charger and freight charge. The sample will be refunded cost when order confirmed.
5. 2 years warranty available:
Every stablizers has 1pcs qualification and 1pcs after-sale service card, customers can get 2 years warranty with the both card

Company Information

FAQ

Q 1. what's the payment terms?

A. We accept LC, T/T, PayPal, Western Union, Small-amount payment, Money Gram
Q 2. how's the delivery time ?
A. usually it will take about two weeks for production
Q 3. tell me the standard of package?
A. For the small capacity, it use carton, but for big capacity, we should use strong wooden case for protection.
Q 4. what kind of material of transformer?
A. For servo type stabilizer,we have two types, one 100% copper and the other is copper with aluminum.It depends on your requirment. In fact,those two have no difference if normal work well. Only except the longlife. Copper is better and also higer price.For relay type stabilizer,we use toroid coils, the material is aluminum. comparing with square coils,toriod coils with high efficiency.
Q 5.Could you offer Form A or C/O ?
A. It totally not a problem. We can prepare relative documents to forgin affairs office or other office to apply for this certificate.
Q 6.Would you accept to use our logo ?
A.If you have good quantity,it absolute no problem to do OEM.
Q 7.We want to know month capacity.
A. It depends on which model.For example for relay type small capacity , month capacity can reach near 10000pcs and big capacity near 2000pcs.
Q 8.Where is your market?
A. Our products are popular inNorth America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europeand so on.Some of them are our regular customers and some of them are developing. We hope you can join us and make mutural benifit from our cooperation.
Q 9. what kind of certificate you have ?
A. Our company already achieve ISO9001, and for products, we have CE,PCT,SGS.
