Specification
Specification /Model |
YK- SPS2000-012 |
YK- SPS2000-015 |
YK- SPS2000-024 |
YK- SPS2000-048 |
YK- SPS2000-060 |
Inrush Current |
180A/230VAC |
||||
Input Current |
11.5A/230VAC |
||||
Efficiency |
84% |
85% |
88% |
89% |
90% |
Power Factor |
0.95/230VAC |
||||
DC Output Voltage |
+12VDC |
+15VDC |
+24VDC |
+48VDC |
+110VDC |
Output Voltage Adjustment |
+3%~-12% Typical adjustment by potentiometer, 20%~100% Adjustment by 1~5VDC external control |
||||
Output Rated Current |
166A |
133A |
83A |
41A |
15A |
Max Output Power |
1992W |
1995W |
1992W |
1968W |
1980W |
Line & Load Regulation |
Less than 1% |
||||
Ripple & Noise(max.) |
150mVp-p |
240mVp-p |
480mVp-p |
600mVp-p |
|
Over Voltage Protection |
110%~135% follow to output set up point(Shut down output voltage, re-power on to recover) |
||||
Over Load Protection |
105~115% rated output power(Current limiting, delay shut down output voltage, re-power on to recover) |
||||
Over Temperature |
>100℃/measure by heat sink, near transformer(shut down output voltage, recovers automatically after temperaure goes down) |
||||
Working Temp., Humidity |
0℃~+50℃ @100% Load, +65℃ @50% Load, 20%~90% RH non-condensing |
||||
Storage Temp., Humidity |
-20℃+85℃, 10%~95% RH |
||||
Temperature Coefficient |
±0.04% / ℃ (0~50℃) |
||||
Withstand Voltage |
I/P~O/P: 3KVAC, I/P~FG: 1.5KVAC, O/P~FG:0.5KVAC |
||||
Isolation Resistance |
I/P~O/P, I/P~FG, O/P~FG:100M Ohms/500VDC |
||||
Power good signal |
Open Collector NPN Transistor |
||||
|
Setup, Rise, Hold Up Time |
500ms, 250ms, 12ms at full load |
||||
Voltage Range |
180~260VAC, 260~370VDC |
||||
Frequency |
47~63Hz |
||||
Leakage Current |
< 10.5mA/240VAC |
||||
Cooling |
Power rating & temperature controlled fan |
||||
Special function |
DC voltage adjustment, Remote sensing, Remote control, Parallel operation |
||||
Safety Standards |
Meet UL1950, TUV EN60950-1 |
||||
EMC Standards |
Meet EN55022, EN610000- 3-2, 3, EN55024 |
||||
MTBF |
74.9K hrs min. MIL-HDBK-217F(25℃) |
||||
Dimension |
320 x 212 x 124mm (L x W x H) |
||||
Weight |
8.9Kgs |
||||
