Help CenterDXDK-100SJ Triangular Diet Teabag Automatic Packing Machine
Related Products
-
DXDK-100SJ Triangular Diet Tea Bag Automatic Packing MachineUS$ 20,000 - 25,000MOQ: 1 Set -
DXDK-100SJ Triangular Flower Tea Package Automatic Packing MachineUS$ 20,000 - 25,000MOQ: 1 Set
-
DXDK-100SJ Triangular Tea Pouch Packaging MachineUS$ 20,000 - 25,000MOQ: 1 Set
-
DXDK-100SJ Triangular Diet Tea Pouch Automatic Packaging MachineUS$ 20,000 - 25,000MOQ: 1 Set
-
DXDK-100SJ Triangular Slimming Tea Pouch Automatic Packaging MachineUS$ 20,000 - 25,000MOQ: 1 Set
Specifications
Triangular Diet Teabag Packing MachinePacking Speed: 3000 Bigs/h
Filling Range: 1-10 ml
Packing Size: 50-80mm/per side
DXDK-100SJ Automatic Electrical Pyramid Tea Bags Packaging Machine
Finished Products
Details
Specification
| Model | DXDK-100SJ |
| Spacing Conveyor | Control by stepping motor and digital switch. Unit: 1mm |
| Packaging Capacity | Up to 50 bags/min |
| Measurement Methods | Sliding volume measures(Standard) or measuring the weight measurement sensors. |
| Packaging Materials | Nylon, polyester mesh, non-woven fabrics, ultrasonic sealing materials |
| Pag's Packing Way | Ultrasonic cut and sealing the triangle bag |
| Tea Bag's Size |
Triangle Bag: 50-80mm(per sides) Rectangular Bag: 60-90mm(W)*40-80mm(L) Packing Material's Width: 120mm, 140mm, 160mm and 180mm |
| Machine's Size | (W*L*H) 1080mm*1310mm*2130mm |
| The use of Electricity |
(Machine) 200V 2Kw (Compression Engine) 200V 2.2Kw |
| Machine Weight | 450Kg |
| Filling Range | 1-10ml |
| Bag Type | Three-side Sealing |
| Packing Material's Width | 120mm, 140mm, 160mm, 180mm 120mm, 140mm, 160mm, 180mm |
Automatic Electrical Triangle Tea Bags Packing Machine
Product Description
This machine is suitable for automatically packing tea in triangle bags.
This packing machine is made by SUS304 stainless steel, and the cylinder is very durable, therefore this packing machine ensures the working accuracy and stablity, meanwhile the packing products' food hygiene can be guaranteed.
This triangle pyramid tea bags packing machine use ultrasonic wave to seal and cut off the pyramid tea bags, these triangle tea bags have terrific water permeability(water is very ease mix with the tea), which can be used to seal green tea, black tea, flower tea, and any other tea. These three-dimensional tea bags have beautiful appearance.
DXDK-100SJ Nylon Fabrics Bag Triangular three-dimensional Tea Bag Packing Machine
Application
This triquetrous tea bags packaging machine is suitable for packaging green tea, black tea, flower tea, coffee, herbal tea, and any other tea, or packing spices which used to making soup, and any other .
DXDK-100SJ Automatic Tea Bag Packing Machine
Features
1. Seal and cut off by ultrasound wave, which makes the beautiful appearance terrific water permeability (water is very ease mix with the tea) tea bag's manufacture become possible.
2. Packaging speed is 3,000 bags/hour.
3. With the labeled packaging materials, the packaging machine can be simply produced with the labeled triquetrous tea bags.
4. With sliding volume filling measurement methods, it can be easily change the filling stuff.
DXDK-100SJ Tea Bag Packing Machinery
Standard Devices
1. Counter.
2. Main motor protection device(Circular overtime).
3. PSA motor control.
4. Sliding volume overload protection device.
5. Stepping motor vertical transmission.
6. Check the label(report when test to an error)
7. Limit switch for open the door safely.
8. Automatic adjustment device for packing material's tension.
9. No packing material warning device.
10. Ultrasonic overload warning.
11. Device for remove static.
12. The machine will automatically stop when the machine has any of the warning.
Optional Devices
1. Automatic measuring devices for measure small amount.
2. Automatically install the device labels.
3. Feeder putt auxiliary storage device.
4. Raw materials slide tapping devices.
5. Sliding volume vibrator.
6. Non-woven counterparts device.
7. Flat bags sealed with vertical device.
8. By use FW-100SA, the raw materials can be precisely measured, which the volume measurement can not do.
Packaging Details:
Wrap the machine by plastic film, and then load the machine into fumigation wooden box, and fasten the machine.
Contact Us
Company Info:
Tianjin Hayetoda Packing Machinery Co., Ltd. is located in the Beichen Technology Industrial Park in Tianjin, which is one of the main deepwater harbors in northern China. Therefore, we enjoy convenient transportation and can ship your goods in a timely manner after confirmation.
Since the establishment in 1999, we have rapidly grown from a small enterprise into a main supplier of packing machinery. Based on an Expert Research and Development Team, we are continually developing new models according to the latest market needs. We now specialize in the supply of granular, powder, sauce and liquid packing machine.
Taking care of all customs’ after-sale service, we hope to have the opportunity of cooperating with your company in the near future.
