CMY 350W 17R Beam,Wash&Spot Moving Head

CMY 350W 17R Beam,Wash&Spot Moving Head thumbnail-1
CMY 350W 17R Beam,Wash&Spot Moving Head photo-1
US$ 600 - 1,499 MOQ: 1 Piece
Key Specifications
Get Latest Price
LED Light Source:
LED
Type:
Moving Head Lights
Input Voltage(V):
100-240
Contact Supplier Request Quote Chat Now
Guangzhou Geliang Lighting Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Huangpu
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source LED
Type Moving Head Lights
Input Voltage(V) 100-240
Lamp Power(W) 620
Lamp Luminous Flux(lm) 52
Lamp Luminous Efficiency(lm/w) 5000
Color Temperature(CCT) Other, Adjustable
Working Temperature(℃) -25, 35
Working Lifetime(Hour) 2200
IP Rating IP33
Certification CE, EMC, LVD
Place of Origin Guangdong, China
Brand Name RIGEBA
Model Number RG-M350B-KNH34
Emitting Color CMY

Specifications

Beam moving head light 17R
1, Spot, Wash & Beam 3 functions in one light
2, 23CH ,CMY, 3 prism,Touch display
3, YODN 17R b

350W 17R Beam,Wash&Spot 3in1 Moving Head







Packaging & Shipping

 Products are shipped by boat or by air



Product Description



TECHNICAL SPECIFICATIONS



Power supply

Power Requirements AC 100V-240V~, / 50Hz/60Hz

Fuse Protection 7A/250V, GMA (5x20mm fine-wire fuse)

Power Consumption 520 Watts

Lamp

Type Platinum 17R

Lamp Wattage 350W

Life time 2200 Hrs

Color temperature 8000K

CRI 75

Optical system

Lenses hardened and tempered, anti-reflex coated

Colors

6 dichroic filter, UV Filter, CTO Filter, plus white, half-color compatible

Gobos

Gobo-wheel 1: 8 interchangeable rotating gobos plus "open"

Gobo-wheel 2: 14 fixed gobos plus "open"

Prism

Rotating 3-facet prism, rotating and variable in speed

Shutter / Strobe / Dimmer

Strobe effect with variable speed

Continuously mechanical dimmer 0 - 100%

Focus

Motor driven focus from far to near

DMX Channels

23 (16bit – default) or 21 (8bit – user selectable) or 34 (16bit – user selectable)

Drive

Standard DMX-512, 3 pole XLR; [+] = Pin 3 [-] = Pin 2 [Ground] = Pin 1 or 5

pole XLR; n/a = Pin 5, n/a = Pin 4, [+] = Pin 3, [-] = Pin 2, [Ground] = Pin 1

Starting DMX [001].

Pan / Tilt

Pan - movement 630° in max. 16 bit resolution

Tilt - movement 270° in max. 16 bit resolution

Weights and Measures

Width of the base 13” / 33.5cm (Including Handles)

Length of the base 14” / 35.9cm (Without Handles)

Width of Head 16.9” / 43.0cm

Height (head vertical) 19.4” /49.4cm

Weight (net) 23 Kgs / 50.6 Lbs

Operating Noise Levels (Base level 46.8dB)

Mode: Auto 1m = 55.9 dB

Mode: High 1m = 56.2 dB

Mode: Auto 1m = 51.6 db (Lamp off)

Ambient Operating Temperature42 43

PLATINUM BEAM 17R

-25°C ~ 45°C

All specifications are subject to change at any time without notice.
