Help CenterCNC Milling Machine M330L Frame for School Educational Training
Related Products
-
Vertical CNC Milling Machine Frame VMC650L Machine BodyUS$ 1 - 30,000MOQ: 1 Set -
High Precision CNC Milling Machine Frame Machine V9 Quality ChoiceUS$ 1 - 30,000MOQ: 1 Set
-
CNC Milling Machine Frame V9US$ 1 - 30,000MOQ: 1 Set
-
CNC Milling and Boring Machine Frame V9 With High PerformanceUS$ 1 - 30,000MOQ: 1 Set
-
CNC Milling and Boring Machine Frame V7 With High PerformanceUS$ 1 - 30,000MOQ: 1 Set
Specifications
1.mini milling machine series2.is suitable for school educational training
3.is applicable to process plate,board,shell molds
Main parameters:
NO. |
ITEM |
Specification |
|||||
1 |
Table size L(mm)×W(mm) |
690×210 |
|||||
2 |
T slot QTY /width/center distance(mm) |
3-16-63 |
|||||
3 |
Maximum load(KG) |
100 |
|||||
4 |
X travel (mm) |
330 |
|||||
5 |
Y travel (mm) |
220 |
|||||
6 |
Z travel (mm) |
320 |
|||||
7 |
Spindle nose to table (mm) |
90-410 |
|||||
8 |
Spindle center to column (mm) |
280 |
|||||
9 |
Spindle taper |
BT30 |
|||||
10 |
Max. spindle speed (Rpm) |
6000 or 8000 |
|||||
11 |
Main motor (kW) |
2.2 |
|||||
|
12
|
Feed motor |
X torque(N.M) |
3.3 |
||||
Y torque(N.M) |
4 |
||||||
Ztorque(N.M) |
5 |
||||||
Max.install size |
X |
Square 90×90diameter φ80 |
|||||
YZ |
Square 110×110diameter φ95 |
||||||
13 |
Rapid moving speed (m/min.) |
10 |
|||||
14 |
Cutting speed (mm/min) |
1-4000 |
|||||
15 |
Ball screw (diametermm/pitch )mm |
20/5 |
|||||
16 |
Linear guide way width( mm) |
20 |
|||||
17 |
Accuracy
|
Positioning accuracy (mm) |
0.02 |
||||
Repeatability accuracy (mm) |
0.01 |
||||||
18 |
Tool changer |
Funnel type (optional ) BT30 |
8 or 6 |
||||
Tool changing time (s) |
8 |
||||||
19 |
Air pressure Mpa |
0.6 |
|||||
20 |
Machine weight (kg) |
Frame |
360 |
||||
Complete machine |
700 |
||||||
21 |
Machine overall size : L(mm)×W(mm)×H(mm) |
Frame |
720×860×1160 |
||||
Complete machine |
1200×1100×2000 |
||||||
Product pictures:
VMC330L frame features:
1.All casting parts adopt advanced HT250 cast iron,after aging treatment,eliminate residual stress,never deform.
2.Foundation is casting structure,so it is stable and high rigidity.
3.Taiwan HIWIN linear guideway,adopt completely support design,so when move to any place within effective stroke,still completely supported by guide way,not inpending,ensure cutting stability,slide's precision and mechanical life.
4.All machines 100% inspected by Renishaw laser interferometer,ensure accuracy of back gap,guarantee position accuarcy.
5.3axes adopt servo motor driving,drive is steady,precision is high,torque force is strong.
6.Stainless steel dust-proof cover for 3axes,protect guideway and ball screw.
Company profile:
We Good CNC Machine company is a professional supplier and experienced manufacture of CNC milling machine and CNC machine center,we have theIS09000 authorization and the right to import and export,it is a provincal-level high-tech enterprise owing 18 patented technology in terms of machine's external appearance design and utility models etc.
We take great importance into innovation,with talented team in research and technology,we are confident to offer you best service and best productions,and we are proud of providing you best technique support in CNC machinery.
We take the quality is the soul of an enterprise,therefore we always put the quality as the first.all our products must pass strict inspection before they leave the factory.
