Help CenterCONCRETE BATCHING PLANT
Related Products
Machine Details |
|
|||
Make |
Name |
WEBER |
|
|
Model |
Name |
WCP - 28 |
|
|
Mixer |
Out Put Capacity |
Cu.M/Hr |
28 Cu.m/ hr |
|
Type of Mixer |
Name |
Pan Type |
|
|
Batch Capacity |
Cu.M/M |
0.5/1 |
|
|
Mixer Motor |
HP |
30 hp Bharat Bijli Make |
|
|
Bins |
Type of Bins |
Name |
Cross Bin |
|
Number of Bins |
Nos |
4 |
|
|
Bin Capacity |
M TON |
15 M TON. |
|
|
Loading Bucket |
Type |
Name |
Skip Bucket |
|
Capacity |
HP |
12.5 HP |
|
|
Water Pump |
Type |
|
MONO BLOCK CENTRIFUGLE |
|
Capacity |
HP |
2 HP |
|
|
No of Pumps |
Nos |
1 |
|
|
Aggregate Conveyor details |
No of Conveyors |
Nos |
1 |
|
Conveyor Motor Capacity |
HP |
10 HP Bharat Bijli MAKE |
|
|
Sand Vibrator |
Capacity |
HP |
0.5 HP |
|
No of Vibrators |
Nos |
1 |
|
|
Cement Feeding |
Make |
Name |
WAM MAKE |
|
Type |
Name |
SCREW CONVEYER |
|
|
Hopper Capacity |
Cu.M |
1000 KG |
|
|
Length |
Meter |
10 MTR |
|
|
Motor Capacity |
HP |
12.5 HP |
|
|
Cement Weighing and Discharge Details |
Capacity |
Ton |
300 KG |
|
Type of Weighing |
HP |
LOAD CELL BASE |
|
|
Type Of Discharge |
|
BUTTERFLY VALVE |
|
|
Cement Vibrator |
Capacity |
HP |
0.5 HP |
|
No of Vibratos |
Name |
1 |
|
|
Aggregate Load Cells |
Type |
Name |
S' Type |
|
Numbers |
Nos |
4 |
|
|
Capacity / Each |
Kg |
2000 kg |
|
|
Water Load Cell |
Type |
Name |
Regular Type |
|
Numbers |
Nos |
2 |
|
|
Capacity / Each |
Kg |
500 kg |
|
|
Type |
Name |
Electronics weight Control |
|
|
Ad Mixture Load Cell |
Type |
Name |
Electronics weight Control |
|
Compressor |
Motor Capacity |
HP |
3 |
|
Control Panel Details |
Type of Control Panel |
Name |
Fully Automatic Microcomputer touch screen PLC BASE batching Control Penal |
|
Make of Electrical Components |
Name |
TC FRANCE / L&T / SNYIDER |
|
|
|
|
|
|||
|
||||
Send Inquiry to This Supplier
