Our machine is a new design which is introduced from foreign countries basic technology. This machine combines washing filling and capping functions in one set. It is very convenient to change bottle size by using bottleneck clamping and bottle suspending technology. The advanced programmable PLC is equipped to control the main machine. The main electric components are all imported from the advanced countries. The parts which will touch water are made of SUS304 stainless steel.
The mahcine has the high degree of automation, beautiful shape, convenient operation and high productivity. All these advantages can help you save time and labor cost. It is an ideal machine to produce mineral water or pure water.
Technical parameter:
Model: |
CXGF 14/12/5 |
CXGF 16/16/6 |
CXGF 18/18/6 |
CXGF 24/24/8 |
CXGF 32/32/10 |
CXGF 40/40/10 |
|
Capacity: 500ml(b/h) |
3000 |
5000 |
7000 |
10000 |
14000 |
18000 |
|
Suitable Bottle: |
150-340 (mm) |
|||||
|
Suitable Cap: |
50-110 mm |
|||||
|
Filling Pressure: |
0.2-0.3 (Mpa) |
|||||
Power(kw): |
2.2 |
3.84 |
3.84 |
5.6 |
6.3 |
7.3 |
Size(mm): |
2400×1670×2350 |
2470×1970×2350 |
2865×2170×2350 |
3700×2570×2350 |
3800×2950×2400 |
4500×3400×2400 |
Weight(kg): |
2500 |
3000 |
4000 |
5000 |
6000 |
8000 |
