1.8m Galaxy UD-181LA Eco-solvet Printer

Name: 1.8m Galaxy UD-181LA Eco-solvet Printer
Brand: Galaxy UD-181LA
SKU: 111562289

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Plate Type:

Other, inkjet solvent printer

Place of Origin:

Guangdong, China

Guangzhou Crystek Electronic Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

guangzhou huangpu

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Plate Type Other, inkjet solvent printer

Place of Origin Guangdong, China

Brand Name Galaxy UD-181LA

Model Number 1.8m Galaxy UD-181LA eco-solvet printer

Usage Paper Printer, Bill Printer

Automatic Grade Automatic

Voltage AC220V

Gross Power 50/60HZ

Dimensions(L*W*H) L3,080 x W990 x H1,260mm

Weight 204kg

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Galaxy UD-181LA inkjet printer with dx5 head
1.1.8m printing width
2. one/two Dx5 head
3. CMKY 4 color
4.1440dpi resolution

1.8m Pheaton Galaxy UD-181LA Eco solvent printer with Epson Dx5 printhead

1. Adport veriable dot printing technology. These are 8 columns of nozzles in the printhead, every column contains 180 nozzles.

1, Using Epson DX5 print head;

2, Full aluminum platform;

3, X,Y axis AC servo motors;

4, Bearing rail is stable and long durability;

5, USB2.0 high speed data port ensure high speed and quality and long scale output printing.

Model	UD-181LA
Print Head	Epson DX5
Number of Print Head	1 Head
Max Printing Width	1800mm
Printing Speed (m2/hr)	Draft	4 pass 16
	Standard	6 pass 11
	Quality	8 pass 9
	High Quality	8 pass 9
	Backlit	12 pass 5
Ink	Type	Waterbased / Eco Solvent Ink
	Color	C M Y K
	Capacity	1 liter
	Ink supply system	Auto ink supply system
Media	Width	Max 1830mm
	Type	Vinyl, film, polyester, flex, backlit film, PS board, KT board, PVC foam board…
Auto Media Feeding System	Equipped Max media weigh 25kgs
Auto Cleaning System	Anti-clogged flash function and capping system
Pre-heating & Drying System	Equipped
Clamp	Equipped
Print Interface	USB2.0
Print Head Height	2-10mm from media
Rip Software	Ultraprint, Maintop, Photoprint, Shiraz, Wasatch
Input Power	AC220v, 50HZ/60HZ
Machine Dimension	L3056 * W970 * H1256mm / 232kgs
Package Dimension	L3190 * W1100 * H870mm / 400kgs
Requirement	Temperature: 20-28 degree, Humidity: 40% - 60%
