Specifications
Hard metal industrial mod engraving and cutting machine1 Lathe bed casting iron frame
2 High accurency
3.thicknes
Hard metal industrial high Accuracy mold engraving and cutting machine
Engraving Machine
Machine parameter
Table Dimension |
640*540 |
MM |
X,Y,Z Working area |
600*600*150 |
MM |
X,Y,Z Position accuracy |
±0.01/300 |
MM |
Table Flatness |
±0.025/300 |
MM |
X,Y Perpendicularity |
0.025/300 |
MM |
Z Height |
150 |
MM |
Spindle Power |
800(optional 1.5, 2.2KW) |
W |
Max Spindle Speed |
24000 |
RPM |
Driving System |
Step |
|
Working Voltage |
Single Phase 220V /50Hz |
V/Hz |
Machine Weight (Net) |
550 |
KG |
Machine Size |
1650*1150*1600 |
MM |
Real factory shows:
Function:
1 |
Whole casting iron frame , to ensure the structure stability , low inertia and no distortion. |
2 |
Japan made dual screw-nut anti-gap rod, high accuracy , low noise, long life. |
3 |
Equipped with high-speed frequency conversion water cooling spindle2.2KW , high-performance division drive can meet the long time continuous work. |
4 |
Powerful compatibility can meet different software:Type3, Wentai,Artam, Castmate other CAD/CA M software. |
Hard metal industrial high Accuracy mold engraving and cutting machine
Trading Terms:
Payment Terms |
T/T , L/C |
Delivery Terms |
FOB Shanghai or Nanjing (Only Domestic). |
Payment Condition |
Payment 30%in advance before shipping to the port (domestic) pay off the balance. |
Packing |
Wooden case with inner plastic proof |
Supply Capacity |
200Sets / Month |
Components:
|
|
|
|
Sample:
|
|
|
|
Certificates:
CE |
ISO9001 |
|
|
Package:
Why you choose Nanjing Chaohan CNC machine?
1. Our Company is specialized in manufacturing and exporting CNC router and laser machine.
We have much export experience and provide the high quality machines with competitive prices.
2. Our machines are widely used in almost all the materials and industries.
3. we provide you one-stop services, including Online Negotiation, Order Confirmation,
Delivery and Transport, Installation Guidance, and After Sales Service
4. We can manufacture the machines in shorter time according to your requirements.
Guarantee & After Sales Service :
1) The machine guarantee is 12 months.
2) 24 hours technical support by email or calling .
3) Friendly English version manual and operation video CD disc.
4) Engineers can serve abroad
5) Distributor abroad for after service available
To provide you detailed quotation, we need to confirm the following details :
1.which kind of materials will be used on this machine2.the Max. size of your materials or the working table size you need, also the thickness you want to engrave on the material
3.What is the working voltage and frequency in your country
4.your sample pictures of your product will be helpful to determine the suitable machine for you
Question time |
Q1.What control system it use ?
A: Ncstudio control system or DSP controlling system.
Q2.Which kind of machine is more suitable for me?
A:It is according to the material and processing thickness and the working area .
Q3.How to support me if i don't know how to use it?
A:free training by online,tel and mail or study in our factory.
Q4.How to transport?
A:By sea
