Specifications
1.CNC mold engraving and milling machine(need Bangal distributor)2.Good quality
3.Competitive price
4.Many material
5.CE
CNC mold engraving and milling machine(need Bangal distributor)
Specifications
High Accuracy CNC Mold Engraving Machine
1 Lathe bed casting iron frame
2 apan made dual screw-nut anti-gap rod
3 CE ISO 9001
Machine parameter
Name |
Parameter |
Model |
SW-60S(600*600*120mm) |
Power of spindle |
2200 W |
Max rotating of spindle |
5000-24000 RPM |
X,Y,Z position accuracy |
±0.005/300 MM |
X,Y,Z reposition accuracy |
±0.01 MM |
X,Y perpendicularity |
±0.025/300 MM |
Height for Z Axis |
300 MM |
Table flatness |
±0.025/300 MM |
X,Y,X working area |
600*600*120 MM |
Working voltage |
220V / 50Hz ±10% or 380V |
Machine weight |
1200 KG |
Machine features:
1 Whole casting iron frame , to ensure the structure stability , low inertia and no distortion.
2 Japan made dual screw-nut anti-gap rod, high accuracy , low noise, long life.
3Equipped with high speed frequency conversion water cooling spindle2.2KW ,
high performance division drive can meet the long time continuous work.
4 Powerful compatibility can meet different software:Type3, Wentai, Artam, Castmate other CAD/CA M software.
Applications
This model mainly used in metal ,nonmetal materials and batching components processing,
Beam stamping mold ,cooper electrode and relevant lines
Our workshop certificate and display
machine
Warranty and Service
Warranty |
One year |
Technical Support |
All Life ( If machine is blocked, please contact us immediately and we will arrange for technical engineer to solve ). |
Our team
package
Why you choose Nanjing Chaohan CNC machine?
1. Our Company is specialized in manufacturing and exporting CNC router and laser machine.
We have much export experience. And we will provide the high quality machines with competitive prices.
2. Our machines are widely used in almost all the materials and industries.
3. we provide you one-stop services, including Online Negotiation, Order Confirmation, Delivery and Transport, Installation Guidance, and After Sales Service
4. We can manufacture the machines in shorter time according to your requirements.
Note:If you are not sure which machine is suitable, please tell me the following questions,
i will recommend the most suitable machine to you.
1) what materials do you want to engrave or cut?
2) what's the max. size of the materials and your products? (Length*Width*Thickness)
