Help CenterUL VDE TUV Approved Mini Rocker Switch for LED Products KCD1-102NC
Related Products
-
UL CE TUV CQC ARC Lighted On-on 3pins Round Mini Rocker SwitchUS$ 0.13 - 0.14MOQ: 5000 Pints -
UL VDE CE 16A Customized Color DPST Rocker Switch KCD4-202ECUS$ 0.25 - 0.3MOQ: 5000 Pieces
-
ON-OFF-ON UL CE Approved Rocker Switch KCD3-103C-TUS$ 0.1 - 0.2MOQ: 5000 Pieces
-
Waterproof4pins 6pins Rocker Switch With Lamp/light Illuminated On-on Double Button DPST Big Current 6P 16A 250V AC KCD4-202NC-2US$ 0.1 - 1MOQ: 1000 Pieces
-
UL VDE CE SLIDE SWITCHUS$ 0.05 - 0.2MOQ: 5000 Pieces
KCD type Rocker Switch Series
Specification |
||
|
rocker switches |
Specification |
|
Rating |
250V 10A AC |
|
Contact resistance |
30mΩ max |
|
Insulation resistance |
100MΩ min |
|
Withstand Voltage |
1500Vac |
|
Lifespan |
10,000-50,000Cycles. |
|
Practical temperature range |
-25 to 85 degrees Celsius |
|
Environmental humidity |
45%-95% |
|
Certification |
UL,VDE,ENEC,CSA,TUV,CE,EMC,CQC,CCC |
|
[Warm Tips]All information above is for reference only; Particulars of all items are base on individual specification. |
||
Regarding to our products: |
More than 2,000 models of switches and sockets.
Monthly production capacity: 30 million pieces.
MOQ: 1,000pcs, it’s negotiable.
Good quality with competitive price.
We can offer free samples with shipping and taxes pay by the buyer.
Various operation force, height, and color for your choice.
The discount depends on your order quantity.
All products are RoHs REACH approved
High quality, stable performance, competitive price, good service.
Warmly welcome to your enquiries.
OEM and ODM orders are also welcomed.
