Specifications
competitive pricewhole welded structure
reliable structure
anti-jamming performance
turbine type flow meter
Features
a) Pulse output, linear feature;
b) High accuracy, sensitive reaction;
c) Wide measuring range;
d) Signal output:
e) Simple structure, easy installation, operation and maintenance;
f) Filter, eliminator and rectifier(aligner) can be provided as a whole package;
g) A pair of companion vice flanges for installation is available.
Specification
Item |
Gas turbine flowmeter |
Liquid turbine flowmeter |
Applicable medium or condition |
Gas |
Liquid |
Caliber(mm) |
15~50 |
10~500 |
Accuracy |
±1.5% |
±1%,±0.5%,±0.2% |
Pressure(MPa) |
2.5~16 |
2.5~16 |
Flow range(m3/h) |
4~200 |
0.25~4000 |
Fluid temperature |
-20°C~+120°C |
-30°C~+80°C |
Ambient |
Temperature: -20°C~+55°C |
Temperature: -30°C~+60°C |
Power source |
8~24V.DC, 3.2V 10AH lithium battery |
|
Signal ouput |
Pulse output(+12~+24VDC power supply, three-wire system) |
|
Explosion-proof grade |
dⅡBT4, ibⅡCT4 |
|
Protection Grade |
IP65 |
|
Available form |
Compact type, Remote type, Inserted type, Bidirectional type |
|
Connecting mode |
Flange connection, Pipe thread connection |
|
Shell material |
SS/CS |
|
