Digital Magnetic Drinking Water Flow Meter Made in China(ISO9001 Manufacture)

Peak flow rate

15m/s

Accuracy

(refer to accuracy curve)

Indication ±0.5%(flow rate no less than 0.8m/s)

Conductibility of fluid

Above 5μ S/cm

Nominal pressure

DN15~ DN150

4.0Mpa

DN15~DN600

1.6Mpa

DN200~DN1000

1.0Mpa

DN200~DN3000

0.6Mpa

Ambient temperature

Sensor

-25~+60 Deg C

Compact flow meter and converter

-10~+60 Deg C

The liner material and maximum temperature of fluid

Liner material

Remote type

Compact type

Polytetrafluoroethylene

(PTFE)

100°C(standard)

150°C(special order)

70°C

Polyvinyl fluoride

(PVF)

100°C(standard)

150°C(special order)

70°C

Fluorinated

ethylene-propylene(FEP)

100°C(standard)

150°C(special order)

70°C

Polychloropree rubber(CR)

80°C(standard)

120°C(special order)

70°C

Polyurethane(PU)

80°C

70°C

Electrode type

Fixed type(DN150~DN2600); Blade type(DN300~DN1600)

Material of signal electrode and grounding electrode

Mo-containing stainless steel, hastelloy B, hastelloy C, tantalum alloy, titanium alloy, platinum-iridium alloy, stainless steel-coated wolfram carbide

Flange material

Carbon steel

Grounding flange material

Stainless steel 1Cr18Ni9Ti

Seal ring material

PTFE

Material of inlet protection flange

DN6~DN600

Stainless steel 1Cr18Ni9Ti

DN700~DN3000

Carbon steel

Shell protection

DN6~DN150 remote sensor with rubber or polyurethane liner

IP65(standard),

IP68(special order)

DN200~DN3000 remote sensor with rubber or polyurethane liner

IP68(able to 5~10m under water usage)

Other sensor and all kinds of converter

IP65

Power supply

24VDC/220VAC

Signal output

Pulse, 4-20mA

Communication

RS485, Modbus(standard),

RS232,HART,Profibus, GPRS(special order)

Display

Digital 2-line LCD, able to display positive and negative instantaneous flow and accumulative flow

Spacing (remote type)

Generally, the spacing between converter and sensor is no longer than 100 meters, special order will be required when it is longer than 100 meters.
