FlintStone 32 Inch Indoor Industrial Embedded Cctv Monitor / Frameless Lcd Monitor With VGA Input

FlintStone 32 inch indoor industrial embedded cctv monitor / frameless lcd monitor with VGA input

What features of our embedded cctv monitor  ?

 1. Industrial-grade design, heavy-duty built for non-stop loop-playing 24/7/365

 2. Rich signal input ports: HDMI / VGA / BNC / AV and more

 3. Metal shielding structure, anti-radiation, anti-static, anti-magnetic, anti-interference

 4. Latest fan-less design, noise-less, dust-less, no potential damage of moving mechanical parts, no potential over heating hazard

 5. Open frame structure: highly flexible and customizable to embed into your furniture, store shelf, wall, or any other objects as per your needs

 6. Our engineers can provide design service as per your special needs

What functions of our embedded cctv monitor  ?

1. Solid open frame structure and flexible brackets for embedding

2. Adopt latest 3D digital filtering and 3D digital noise reduction technology

3. Professional industrial A+ LCD panel

4. 16.7M color, true presentation of all the details

5. High brightness, high color gamut, high contrast ratio to improve the image performance

6. 5ms response time; 60,000 hours life span

7. With both flexible push buttons and IR remote control

What are the specifications of our embedded cctv monitor ?

1. LCD screen

  LCD size: 31.5 inch

  Active area: 697.685mm (H) X 392.256mm (V)

  Screen ratio: 16:9

  Resolution: 1366 X 768

  Brightness: 450cd/m2

  Contrast ratio: 1400:1

  View angle: L / R / U / D (85° / 85° / 80° / 80°)

  Pixel: 0.51075mm X 0.51075mm

  Color: 24 bit

  Vertical synchronization range: 50-75 HZ

  Horizontal synchronization range: 30-80 KHZ

2. Video

  Color system: PAL, SECAM, NTSC, etc.

  3D comb filter: yes

  3D de-interlace: yes

3. Input and output

  VGA input interface: X 1 (D-Sub 15 pin female)

  HDMI input interface: X 1 (19P standard HDMI interface)

  AV input: X 2 (BNC interface)

  AV output: X 1 (BNC interface)

  Audio input: X 1 (headphone socket)

  Audio output: X 1 (headphone socket)

4. OSD display (screen menu display)

  Menu language: Chinese, English

5. Casing

  Casing material: steel

  Casing color: black

  VESA pitch: 200mm X 200mm,Φ6mm

  Function buttons: 7 buttons

  AC cable length: 1.5 M

6. Others

  Power consumption: AC100~240V 1A(MAX)

  Standby power consumption: <1W

  Speaker power: 2 X 8 Ω / 6 W

  Body size: 802mm (L) X 492mm (W) X 77mm (H)

  Net weight: 20kg

  Package: neutral packaging

  Accessories: power adapter, remote control, etc.

  Standard bracket: L shape bracket

  Application environment: indoor

  Working temperature: 0℃ - 45℃

  Storage temperature: -20℃ - 45℃

  Working humidity: 20% - 80%

  Storage humidity: 10% - 95%

embedded cctv monitor   photos

What is the application of embedded cctv monitor ?

- Post ads

- Publish the latest information
- Real-time news
- The latest product photos
- Exhibition information
- Corporate incentive information
- Welcome Board
- Brand promotion
- Product promotion
- Entertainment platform
- Education platform
- Information sharing
- Media platform operation

  More ... ...

- Industrial display

- Traffic control room

- Video wall

- Corporate board room

- Exhibition center

- Video conference room

- Government bodies

- Product promotion

- Entertainment platform

- Education & training

- Military command room

- Public data

More ... ...
